  4. Schneider MG EZC100 H 30kA 3P/3T 35A

Schneider MG EZC100 H 30kA 3P/3T 35A

Rp 1,721,443.00 Rp 809,078.00 809078 IDR

Rp 1,721,443.00

Option not available

    This combination does not exist.

    Add to Cart

    Schneider MG EZC100 H 30kA 3P/3T 35A
    Terjual 0
    0 (0 Rating)
    Ulasan (0)

    Rp 809,078.00
    53.00 % Rp 1,721,443.00 809078 IDR

    Rp 1,721,443.00

    Option not available

    Atur Jumlah & Catatan
    Stock Total: 91
    Keranjang Beli Sekarang
    Spesifikasi
    Main (see above)
    range of product
    EasyPact

    product or component type
    Circuit breaker

    device short name
    Easypact EZC100H

    circuit breaker name
    Easypact EZC100H

    device application
    Distribution

    poles description
    3P

    protected poles description
    3t

    network type
    DC
    AC

    network frequency
    50/60 Hz

    [In] rated current
    100 A at 40 °C

    [Ui] rated insulation voltage
    690 V AC 50/60 Hz conforming to IEC 60947-2

    [Uimp] rated impulse withstand voltage
    6 kV conforming to IEC 60947-2

    [Ue] rated operational voltage
    550 V AC 50/60 Hz conforming to IEC 60947-2
    250 V DC conforming to IEC 60947-2

    breaking capacity code
    H

    breaking capacity
    10 kA Icu at 125 V DC 1P conforming to IEC 60947-2
    10 kA Icu at 250 V DC 2P conforming to IEC 60947-2
    10 kA Icu at 550 V AC 50/60 Hz conforming to IEC 60947-2
    100 kA Icu at 110...130 V AC 50/60 Hz conforming to IEC 60947-2
    20 kA Icu at 440 V AC 50/60 Hz conforming to IEC 60947-2
    50 kA Icu at 220...240 V AC 50/60 Hz conforming to IEC 60947-2
    30 kA Icu at 380...400 V AC 50/60 Hz conforming to IEC 60947-2
    30 kA Icu at 415 V AC 50/60 Hz conforming to IEC 60947-2

    [Ics] rated service breaking capacity
    5 kA at 125 V DC conforming to IEC 60947-2
    5 kA at 250 V DC conforming to IEC 60947-2
    5 kA at 440 V AC 50/60 Hz conforming to IEC 60947-2
    2.5 kA at 550 V AC 50/60 Hz conforming to IEC 60947-2
    15 kA at 380...400 V AC 50/60 Hz conforming to IEC 60947-2
    25 kA at 220...240 V AC 50/60 Hz conforming to IEC 60947-2
    50 kA at 110...130 V AC 50/60 Hz conforming to IEC 60947-2
    7.5 kA at 415 V AC 50/60 Hz conforming to IEC 60947-2

    suitability for isolation
    Yes conforming to IEC 60947-2

    utilisation category
    Category A

    trip unit name
    TM-D

    trip unit technology
    Thermal-magnetic

    trip unit rating
    35 A at 50 °C

    protection type
    Overload protection
    Short-circuit protection

    pollution degree
    3 conforming to IEC 60947

    Complementary (see above)
    control type
    Toggle

    mounting mode
    Fixed

    mounting support
    Backplate

    upside connection
    Front

    downside connection
    Front

    mechanical durability
    8500 cycles

    electrical durability
    Category A: 1500 cycles 415 V AC 50/60 Hz conforming to IEC 60947-2

    connection pitch
    25 mm

    local signalling
    Positive contact indication

    neutral protection setting
    Without protection

    earth-leakage protection
    Without

    height
    130 mm

    width
    75 mm

    depth
    60 mm

    Environment (see above)
    standards
    EN/IEC 60947-1
    JIS C8201-2-2
    EN/IEC 60947-2
    GB/T 14048.2

    IP degree of protection
    IP20 conforming to IEC 60529

    IK degree of protection
    IK07 conforming to EN 50102

    ambient air temperature for operation
    -25…70 °C

    ambient air temperature for storage
    -35…85 °C

    Packing Units (see above)
    Unit Type of Package 1
    PCE

    Number of Units in Package 1
    1

    Package 1 Weight
    819 g

    Package 1 Height
    9.5 cm

    Package 1 width
    14 cm

    Package 1 Length
    8.5 cm

    Offer Sustainability (see above)
    Sustainable offer status
    Green Premium product

    REACh Regulation
    REACh free of SVHC
    Yes

    EU RoHS Directive
    Toxic heavy metal free
    Yes

    Mercury free
    Yes

    RoHS exemption information
    China RoHS Regulation
    Environmental Disclosure
    WEEE
    The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins

    Contractual warranty (see above)
    Warranty
    12 months
