Schneider Circuit breaker EasyPact CVS100F, 36 kA at 415 VAC, 63 A rating thermal magnetic TM-D trip unit, 4P 3d

# of Pole : 4

Arus Nominal (In) : 63A

Icu (kA) : 36

Rp 2,714,194.00 Rp 1,411,380.00 1411380 IDR

Rp 2,714,194.00

Option not available

  • # of Pole
  • Arus Nominal (In)
  • Icu (kA)

This combination does not exist.

Add to Cart

Schneider Circuit breaker EasyPact CVS100F, 36 kA at 415 VAC, 63 A rating thermal magnetic TM-D trip unit, 4P 3d
Terjual 0
0 (0 Rating)
Ulasan (0)

Rp 1,411,380.00
48.00 % Rp 2,714,194.00 1411380 IDR

Rp 2,714,194.00

Option not available

Atur Jumlah & Catatan
Stock Total: Out of Stock

# of Pole : 4

Arus Nominal (In) : 63A

Icu (kA) : 36

Spesifikasi
Main (see above)
range of product
Easypact CVS100...250
product or component type
Circuit breaker
device short name
CVS100F
device application
Distribution
poles description
4P
protected poles description
4d
neutral position
Left
Earth leakage protection (Vigi add on)
Without
[In] rated current
100 A at 40 °C
breaking capacity code
F
network type
AC
[Icu] Breaking capacity
36 kA Icu at 440 V AC 50/60 Hz conforming to IEC 60947-2
36 kA Icu at 380/415 V AC 50/60 Hz conforming to IEC 60947-2
70 kA Icu at 220/240 V AC 50/60 Hz conforming to IEC 60947-2
utilisation category
Category A
trip unit name
TM-D
trip unit technology
Thermal-magnetic
trip unit rating
63 A at 40 °C
protection type
Short-circuit protection (magnetic)
Overload protection (thermal)
Complementary (see above)
network frequency
50/60 Hz
control type
Toggle
mounting mode
Fixed
mounting support
Backplate
upside connection
Front
downside connection
Front
connections - terminals
Screw connection
[Uimp] rated impulse withstand voltage
8 kV conforming to EN/IEC 60947-2
thermal protection adjustment range
44.1…63 A
[Ics] rated service breaking capacity
18 kA at 440 V AC 50/60 Hz conforming to IEC 60947-2
36 kA at 380/415 V AC 50/60 Hz conforming to IEC 60947-2
70 kA at 220/240 V AC 50/60 Hz conforming to IEC 60947-2
mechanical durability
30000 cycles
electrical durability
12000 cycles 415 V In conforming to IEC 60947-2
connection pitch
35 mm
contact position indicator
Yes
neutral protection setting
1 x Ir (4d)
long time pick-up adjustment type Ir
Adjustable
long time pick-up adjustment range
0.7...1 x In
long time delay adjustment type
Fixed
instantaneous pick-up adjustment type Ii
Fixed
instantaneous pick-up adjustment range
500 A
height
161 mm
width
140 mm
depth
86 mm
net weight
2.2 kg
Environment (see above)
electrical shock protection class
Class II
standards
IEC 60947-2
EN 60947-2
product certifications
GOST
IEC
IP degree of protection
IP40
pollution degree
3 conforming to IEC 60664-1
ambient air temperature for operation
-25…70 °C
ambient air temperature for storage
-50…85 °C
Packing Units (see above)
Unit Type of Package 1
PCE
Number of Units in Package 1
1
Package 1 Weight
2.17 kg
Package 1 Height
13.5 cm
Package 1 width
14.5 cm
Package 1 Length
19 cm
Offer Sustainability (see above)
Sustainable offer status
Green Premium product
REACh Regulation
EU RoHS Directive
Mercury free
Yes
RoHS exemption information
China RoHS Regulation
China RoHS declaration
Product out of China RoHS scope. Substance declaration for your information
Environmental Disclosure
Circularity Profile
WEEE
The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins
Contractual warranty (see above)
Warranty
12 months

Specifications for Schneider Circuit breaker EasyPact CVS100F, 36 kA at 415 VAC, 63 A rating thermal magnetic TM-D trip unit, 4P 3d

# of Pole 4
Arus Nominal (In) 63A
Icu (kA) 36
