  4. Schneider TeSys LC1D.K capacitor duty contactor - 3P - 25 kVAR - 415 V - 220 V AC coil

Schneider TeSys LC1D.K capacitor duty contactor - 3P - 25 kVAR - 415 V - 220 V AC coil

# of Pole : 3

Coil AC : 220V (M7)

Rp 2,973,723.00 Rp 1,665,284.00 1665284 IDR

Rp 2,973,723.00

Option not available

  • # of Pole
  • Coil AC

This combination does not exist.

Add to Cart

Schneider TeSys LC1D.K capacitor duty contactor - 3P - 25 kVAR - 415 V - 220 V AC coil
Terjual 0
0 (0 Rating)
Ulasan (0)

Rp 1,665,284.00
44.00 % Rp 2,973,723.00 1665284 IDR

Rp 2,973,723.00

Option not available

Atur Jumlah & Catatan
Stock Total: 34

# of Pole : 3

Coil AC : 220V (M7)

Keranjang Beli Sekarang
Spesifikasi

[Deskripsi] 1. poles description : 3P 2. power pole contact composition : 3 NO 3. device location in system : -Line interruption -Inside delta interruption 4. [Ue] rated operational voltage : Power circuit: <= 690 V AC 50/60 Hz 5. reactive power rating : -14 kvar at 230 V AC 50/60 Hz 60 °C -25 kvar at 400…415 V AC 50/60 Hz 60 °C -27 kvar at 440 V AC 50/60 Hz 60 °C -42 kvar at 660…690 V AC 50/60 Hz 60 °C 6. control circuit type : AC at 50/60 Hz 7. [Uc] control circuit voltage : 220 V AC 50/60 Hz 8. auxiliary contact composition : -1 NO + 2 NC for signalling circuit -3 NO early make for power circuit 9. height : 125 mm 10. width : 45 mm 11. depth : 127 mm 12. net weight : 0.63 kg


Main (see above)
range
TeSys
product name
TeSys LC1D.K
product or component type
Capacitor duty contactor
device short name
LC1DMK
device application
Control
contactor application
Power factor correction
utilisation category
AC-6b
poles description
3P
power pole contact composition
3 NO
device location in system
Line interruption
Inside delta interruption
[Ue] rated operational voltage
Power circuit: 690 V AC 50/60 Hz
reactive power rating
14 kvar at 230 V AC 50 Hz 60 °C
25 kvar at 400 V AC 50 Hz 60 °C
27 kvar at 440 V AC 50 Hz 60 °C
42 kvar at 690 V AC 50 Hz 60 °C
control circuit type
AC at 50/60 Hz
[Uc] control circuit voltage
220 V AC 50/60 Hz
auxiliary contact composition
1 NO + 2 NC instantaneous
electrical durability
300000 cycles at Ue 400 V
200000 cycles at Ue 690 V
mounting support
DIN rail
Plate
standards
EN/IEC 60947-1
EN/IEC 60947-4-1
product certifications
IECEE CB Scheme
connections - terminals
Control circuit: screw clamp terminals 1 1…4 mm² - cable stiffness: solid
Control circuit: screw clamp terminals 2 1…4 mm² - cable stiffness: solid
Control circuit: screw clamp terminals 1 1…4 mm² - cable stiffness: flexible without cable end
Control circuit: screw clamp terminals 2 1…4 mm² - cable stiffness: flexible without cable end
Control circuit: screw clamp terminals 1 1…4 mm² - cable stiffness: flexible with cable end
Control circuit: screw clamp terminals 2 1…2.5 mm² - cable stiffness: flexible with cable end
Power circuit: screw clamp terminals 1 2.5…16 mm² - cable stiffness: solid
Power circuit: screw clamp terminals 2 2.5…6 mm² - cable stiffness: solid
Power circuit: screw clamp terminals 1 1.5…10 mm² - cable stiffness: flexible without cable end
Power circuit: screw clamp terminals 2 1.5…6 mm² - cable stiffness: flexible without cable end
Power circuit: screw clamp terminals 1 1…10 mm² - cable stiffness: flexible with cable end
Power circuit: screw clamp terminals 2 1…4 mm² - cable stiffness: flexible with cable end
tightening torque
Control circuit: 1.7 N.m - on screw clamp terminals
Power circuit: 2.5 N.m - on screw clamp terminals
maximum operating rate
240 cyc/h
Complementary (see above)
auxiliary contacts type
type mechanically linked 1 NO + 2 NC conforming to IEC 60947-5-1
Environment (see above)
IP degree of protection
IP20 front face conforming to IEC 60529
ambient air temperature for operation
-5…60 °C
ambient air temperature for storage
-60…80 °C
operating altitude
0...3000 m
height
125 mm
width
45 mm
depth
127 mm
net weight
0.63 kg
Packing Units (see above)
Unit Type of Package 1
PCE
Number of Units in Package 1
1
Package 1 Weight
608 g
Package 1 Height
6.6 cm
Package 1 width
19.5 cm
Package 1 Length
22.5 cm
Unit Type of Package 2
S03
Number of Units in Package 2
6
Package 2 Weight
4.075 kg
Package 2 Height
30 cm
Package 2 width
30 cm
Package 2 Length
40 cm
Unit Type of Package 3
P06
Number of Units in Package 3
48
Package 3 Weight
43.388 kg
Package 3 Height
80 cm
Package 3 width
80 cm
Package 3 Length
60 cm
Offer Sustainability (see above)
Sustainable offer status
Green Premium product
REACh Regulation
REACh free of SVHC
Yes
EU RoHS Directive
Toxic heavy metal free
Yes
Mercury free
Yes
RoHS exemption information
China RoHS Regulation
China RoHS declaration
 Pro-active China RoHS declaration (out of China RoHS legal scope)
Environmental Disclosure
WEEE
The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins
Contractual warranty (see above)
Warranty
12 months
