  5. Schneider On-delay timing relay - 0.1 s..100 h - 24 V DC - 2 OC

Schneider On-delay timing relay - 0.1 s..100 h - 24 V DC - 2 OC

Rp 558,502.00 Rp 323,931.00 323931 IDR

Rp 558,502.00

Option not available

    This combination does not exist.

    Add to Cart

    Schneider On-delay timing relay - 0.1 s..100 h - 24 V DC - 2 OC
    Terjual 0
    0 (0 Rating)
    Ulasan (0)

    Rp 323,931.00
    42.00 % Rp 558,502.00 323931 IDR

    Rp 558,502.00

    Option not available

    Atur Jumlah & Catatan
    Stock Total: Out of Stock
    Keranjang Beli Sekarang
    Spesifikasi
    Main (see above)
    range of product
    Harmony Timer Relays
    product or component type
    Single function relay
    fixing mode
    Plug-in (socket)
    discrete output type
    Relay
    contacts type and composition
    2 C/O
    component name
    REXL
    time delay type
    Power on-delay
    time delay range
    1...10 s
    1...10 min
    6...60 min
    0.1...1 s
    1...10 h
    10...100 h
    6...60 s
    Complementary (see above)
    contacts material
    Cadmium free
    [Us] rated supply voltage
    24 V DC
    voltage range
    0.9...1.1 Us
    [In] rated current
    5 A AC
    repeat accuracy
    +/- 0.5 %
    setting accuracy of time delay
    10 % at full scale at 25 °C conforming to EN/IEC 61812-1
    temperature drift
    0.05 %/°C
    maximum reset time
    250 ms after time delay, on de-energisation
    50 ms during time delay, on de-energisation
    voltage drift
    +/- 0.2 %/V
    maximum switching capacity
    4 x 5 A
    maximum temporary permissible current
    10 A for < 10 s
    minimum switching current
    100 mA
    electrical durability
    100000 cycles at 250 V AC resistive
    mechanical durability
    10000000 cycles
    maximum power consumption
    1.2 W
    [Ui] rated insulation voltage
    250 V conforming to IEC 255 Group C
    250 V conforming to VDE 0010
    output overvoltage protection
    2 J
    surge withstand
    2 kV conforming to EN/IEC 61000-4-5 level 3
    creepage distance
    4 kV/3 conforming to IEC 60664-1
    local signalling
    1 LED (red) for output in operation
    1 LED (yellow) for power ON
    net weight
    0.05 kg
    Environment (see above)
    immunity to microbreaks
    5 ms
    dielectric strength
    2 kV for 1 mA/1 minute at 50 Hz conforming to EN/IEC 60601-1
    2 kV for 1 mA/1 minute at 50 Hz conforming to EN/IEC 61812-1
    standards
    73/23/EEC
    EN 50081-2
    93/68/EEC
    EN/IEC 61812-1
    EN 61000-6-2
    EN/IEC 60601-1
    EN/IEC 60601-2
    89/336/EEC
    product certifications
    CUL
    UL
    ambient air temperature for operation
    -20…60 °C
    ambient air temperature for storage
    -40…70 °C
    IP degree of protection
    IP50 conforming to IEC 60529
    vibration resistance
    0.35 mm (f= 10…55 Hz) conforming to IEC 60068-2-6
    relative humidity
    95 % without condensation conforming to IEC 60068-2-6
    resistance to electrostatic discharge
    6 kV in contact conforming to EN/IEC 61000-4-2 level 3
    8 kV in air conforming to EN/IEC 61000-4-2 level 3
    resistance to electromagnetic fields
    10 V/m conforming to EN/IEC 61000-4-3 level 3
    resistance to fast transients
    2 kV conforming to EN/IEC 61000-4-4 level 3
    immunity to radioelectric fields
    10 V (0.15...80 MHz) conforming to EN/IEC 61000-4-6 level 3
    immunity to voltage dips
    >= 95 % / 1 s conforming to EN/IEC 61000-4-11
    30 % / 10 ms conforming to EN/IEC 61000-4-11
    60 % / 100 ms conforming to EN/IEC 61000-4-11
    disturbance radiated/conducted
    Class B conforming to EN 55022 (EN 55011 group 1)
    Packing Units (see above)
    Unit Type of Package 1
    PCE
    Number of Units in Package 1
    1
    Package 1 Weight
    51 g
    Package 1 Height
    3.072 cm
    Package 1 width
    3.079 cm
    Package 1 Length
    7.431 cm
    Offer Sustainability (see above)
    Sustainable offer status
    Green Premium product
    REACh Regulation
    EU RoHS Directive
    Pro-active compliance (Product out of EU RoHS legal scope)
    EU RoHS Declaration
    Mercury free
    Yes
    RoHS exemption information
    China RoHS Regulation
    Environmental Disclosure
    WEEE
    The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins
    California proposition 65
    WARNING: This product can expose you to chemicals including: Nickel compounds, which is known to the State of California to cause cancer, and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
    Contractual warranty (see above)
    Warranty
    12 months
