  4. Schneider MIXED SOCKET SCREW CALMP FOR RXM2/4

Schneider MIXED SOCKET SCREW CALMP FOR RXM2/4

Rp 65,511.00 Rp 37,996.00 37996 IDR

Rp 65,511.00

Option not available

    This combination does not exist.

    Add to Cart

    Schneider MIXED SOCKET SCREW CALMP FOR RXM2/4
    Terjual 0
    0 (0 Rating)
    Ulasan (0)

    Rp 37,996.00
    42.00 % Rp 65,511.00 37996 IDR

    Rp 65,511.00

    Option not available

    Atur Jumlah & Catatan
    Stock Total: 284
    Keranjang Beli Sekarang
    Spesifikasi
    Main (see above)
    range of product
    Harmony Electromechanical Relays
    Harmony Timer Relays
    product or component type
    Socket
    contact terminal arrangement
    Mixed
    product compatibility
    Plug-in relay RXM with 2 C/O contact
    Plug-in relay RXM with 4 C/O contact
    shape of pin
    Flat
    device short name
    RXZ
    sale per indivisible quantity
    10
    Complementary (see above)
    [Ith] conventional free air thermal current
    10 A
    [Ue] rated operational voltage
    < 250 V
    connections - terminals
    Screw clamp terminals, 1 x 0.25...1 x 1 mm² (AWG 22...AWG 17) flexible with cable end
    Screw clamp terminals, 2 x 0.25...2 x 1 mm² (AWG 22...AWG 17) flexible with cable end
    Screw clamp terminals, 1 x 0.5...1 x 1.5 mm² (AWG 20...AWG 16) solid without cable end
    Screw clamp terminals, 2 x 0.5...2 x 1.5 mm² (AWG 20...AWG 16) solid without cable end
    tightening torque
    < 1 N.m for M3 screw(s)
    fixing mode
    By screw (panel)
    Clip-on (35 mm symmetrical DIN rail)
    marking
    CE
    width
    30 mm
    net weight
    0.048 kg
    Environment (see above)
    standards
    IEC 61984
    product certifications
    UL
    CSA
    Lloyd's
    ambient air temperature for storage
    -40…85 °C
    ambient air temperature for operation
    -40…55 °C
    IP degree of protection
    IP20 conforming to EN/IEC 60529
    dielectric strength
    2500 V
    Packing Units (see above)
    Unit Type of Package 1
    PCE
    Number of Units in Package 1
    1
    Package 1 Weight
    52 g
    Package 1 Height
    38.96 mm
    Package 1 width
    30.05 mm
    Package 1 Length
    82.18 mm
    Unit Type of Package 2
    BB1
    Number of Units in Package 2
    10
    Package 2 Weight
    559 g
    Package 2 Height
    7.2 cm
    Package 2 width
    8.5 cm
    Package 2 Length
    15.5 cm
    Unit Type of Package 3
    S03
    Number of Units in Package 3
    200
    Package 3 Weight
    11.621 kg
    Package 3 Height
    30 cm
    Package 3 width
    30 cm
    Package 3 Length
    40 cm
    Offer Sustainability (see above)
    Sustainable offer status
    Green Premium product
    REACh Regulation
    REACh free of SVHC
    Yes
    EU RoHS Directive
    Pro-active compliance (Product out of EU RoHS legal scope)
    EU RoHS Declaration
    Toxic heavy metal free
    Yes
    Mercury free
    Yes
    RoHS exemption information
    China RoHS Regulation
    Environmental Disclosure
    WEEE
    The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins
    Contractual warranty (see above)
    Warranty
    12 months
