Schneider Switch disconnector, Compact INS125 , 125 A, standard version with black rotary handle, 3 poles
# of Pole : 3
Arus Nominal (In) : 125A
Schneider Switch disconnector, Compact INS125 , 125 A, standard version with black rotary handle, 3 poles
Terjual 0
0 (0 Rating)
Ulasan (0)
Rp 1.335.818,00
44.00 %
Rp 2.385.390,00
Rp 2.385.390,00
Option not available
Spesifikasi
| range | ComPact | |
|---|---|---|
| product name | Compact INS | |
| product or component type | Switch disconnector | |
| poles description | 3P | |
| network type | AC DC | |
| network frequency | 50/60 Hz | |
| [Ie] rated operational current | AC-22A: 125 A AC 50/60 Hz 220/240 V AC-22A: 125 A AC 50/60 Hz 380/415 V AC-22A: 125 A AC 50/60 Hz 440/480 V AC-22A: 125 A AC 50/60 Hz 500 V AC-22A: 125 A AC 50/60 Hz 660/690 V AC-23A: 125 A AC 50/60 Hz 220/240 V AC-23A: 125 A AC 50/60 Hz 380/415 V AC-23A: 125 A AC 50/60 Hz 440/480 V AC-23A: 125 A AC 50/60 Hz 500 V AC-23A: 80 A AC 50/60 Hz 660/690 V DC-22A: 125 A DC 125 V 2 poles in series DC-23A: 125 A DC 125 V 2 poles in series | |
| [Ui] rated insulation voltage | 750 V AC 50/60 Hz | |
| [Uimp] rated impulse withstand voltage | 8 kV | |
| [Ith] conventional free air thermal current | 125 A at 60 °C | |
| [Icm] rated short-circuit making capacity | 154 kA with upstream protection circuit breaker 690 V AC at 50/60 Hz 20 kA switch-disconnector alone 690 V AC at 50/60 Hz | |
| [Ue] rated operational voltage | 125 V DC 690 V AC 50/60 Hz | |
| suitability for isolation | Yes | |
| contact position indicator | Yes | |
| visible break | No | |
| pollution degree | 3 |
| control type | Rotary handle | |
|---|---|---|
| handle colour | Black | |
| mounting mode | Fixed | |
| mounting support | DIN rail Plate | |
| upside connection | Front | |
| downside connection | Front | |
| maximum power | AC-23: 55 kW at 440 V AC 50/60 Hz AC-23: 37 kW at 220/240 V AC 50/60 Hz AC-23: 55 kW at 380/415 V AC 50/60 Hz AC-23: 75 kW at 500/525 V AC 50/60 Hz AC-23: 75 kW at 660/690 V AC 50/60 Hz | |
| rated duty | Uninterrupted | |
| intermittent duty class | Class 120 - 60 % | |
| enclosure dimensions for Ithe | 260 mm x 160 mm x 55 mm | |
| [Icw] rated short-time withstand current | 0.01 kA during 30 s conforming to IEC 60947-3 1.23 kA during 20 s conforming to IEC 60947-3 3.175 kA during 3 s conforming to IEC 60947-3 5.5 kA during 1 s conforming to IEC 60947-3 | |
| mechanical durability | 15000 cycles | |
| electrical durability | AC-22A: 1500 cycles 220/240 V AC 50/60 Hz AC-22A: 1500 cycles 380/415 V AC 50/60 Hz AC-22A: 1500 cycles 440 V AC 50/60 Hz AC-22A: 1500 cycles 500 V AC 50/60 Hz AC-23A: 1500 cycles 220/240 V AC 50/60 Hz AC-23A: 1500 cycles 380/415 V AC 50/60 Hz AC-23A: 1500 cycles 440 V AC 50/60 Hz AC-23A: 1500 cycles 500 V AC 50/60 Hz DC-22A: 1500 cycles 250 V DC 2 poles in series DC-23A: 1500 cycles 250 V DC 2 poles in series AC-22A: 1500 cycles 690 V AC 50/60 Hz AC-23A: 1500 cycles 690 V AC 50/60 Hz | |
| connection pitch | 30 mm | |
| height | 100 mm | |
| width | 135 mm | |
| depth | 62.5 mm | |
| net weight | 0.8 kg |
| standards | IEC 60947-1 IEC 60947-3 | |
|---|---|---|
| product certifications | CCC KEMA-KEUR | |
| IP degree of protection | IP40 conforming to IEC 60529 | |
| IK degree of protection | IK07 conforming to EN 50102 | |
| ambient air temperature for operation | -25…70 °C | |
| ambient air temperature for storage | -50…85 °C |
| Unit Type of Package 1 | PCE | |
|---|---|---|
| Number of Units in Package 1 | 1 | |
| Package 1 Weight | 1.026 kg | |
| Package 1 Height | 11.446 cm | |
| Package 1 width | 13.235 cm | |
| Package 1 Length | 15.352 cm |
| Sustainable offer status | Green Premium product | |
|---|---|---|
| REACh Regulation | ||
| REACh free of SVHC | Yes | |
| EU RoHS Directive | Compliant EU RoHS Declaration | |
| Toxic heavy metal free | Yes | |
| Mercury free | Yes | |
| RoHS exemption information | ||
| China RoHS Regulation | ||
| Environmental Disclosure | ||
| WEEE | The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins |
| Warranty | 12 months |
|---|
Specifications for Schneider Switch disconnector, Compact INS125 , 125 A, standard version with black rotary handle, 3 poles
