Schneider Non - adjustable time delay relay for voltage release MN - 200/250 V AC/DC

Rp 5,438,678.00 Rp 2,828,112.00 2828112 IDR

Rp 5,438,678.00

Option not available

    This combination does not exist.

    Add to Cart

    Schneider Non - adjustable time delay relay for voltage release MN - 200/250 V AC/DC
    Terjual 0
    0 (0 Rating)
    Ulasan (0)

    Rp 2,828,112.00
    48.00 % Rp 5,438,678.00 2828112 IDR

    Rp 5,438,678.00

    Option not available

    Atur Jumlah & Catatan
    Stock Total: 2
    Spesifikasi
    Main (see above)
    device short name
    MN delay unit
    product or component type
    Time delay relay
    device application
    Control
    range compatibility
    MasterPact NT
    Masterpact NW
    ComPact NS630b...1600
    ComPact NS1600b...3200
    Masterpact NW UL 489
    Masterpact NT UL 489
    Masterpact NW DC
    voltage release type
    Undervoltage release
    [Uc] control circuit voltage
    200...250 V AC 50/60 Hz
    200...250 V DC
    Complementary (see above)
    impulse duration
    200 ms
    time delay range
    0.25 s
    threshold tripping voltage
    0.35...0.7 Un open
    0.85 Un close
    supply holding power
    4.5 VA
    supply inrush power
    200 VA
    mounting mode
    External mounting
    response time
    0.25 s
    accessory / separate part category
    Spare part for Compact NS630b...1600
    Spare part for Compact NS1600b...3200
    Packing Units (see above)
    Unit Type of Package 1
    PCE
    Number of Units in Package 1
    1
    Package 1 Weight
    148 g
    Package 1 Height
    7.6 cm
    Package 1 width
    8.5 cm
    Package 1 Length
    9 cm
    Unit Type of Package 2
    S03
    Number of Units in Package 2
    36
    Package 2 Weight
    5.73 kg
    Package 2 Height
    30 cm
    Package 2 width
    30 cm
    Package 2 Length
    40 cm
    Offer Sustainability (see above)
    REACh Regulation
    EU RoHS Directive
    Pro-active compliance (Product out of EU RoHS legal scope)
    EU RoHS Declaration
    Mercury free
    Yes
    RoHS exemption information
    China RoHS Regulation
    China RoHS declaration
    Product out of China RoHS scope. Substance declaration for your information
    PVC free
    Yes
    Contractual warranty (see above)
    Warranty
    12 months
