[Deskripsi] MCB C60H-DC Direkomendasikan untuk digunakan pada distribusi listrik di Gedung dan industri. -Kurva C (Magnetis trip antara 5 dan 10 In) -Lebar modul per kutub = 18 mm. -Breaking Capacity (Icu): 1 Kutub = 20kA DI 110vdc, 10kA di 220VDC 2 Kutub (seri) = 20kA di 220VDC, 10kA di 440VDC -Cocok untuk aplikasi : -Gedung komersil dan industry -Power Supply : otomatis industri, sirkuit auxiliary untuk tegangan menengah, pengisian daya baterai dan UPS, keamanan sistem daya (power system) aplikasi telekomunikasi -Transportasi : kereta api, kendaraan listrik, aplikasi kapal laut -Pembangkit listrik : tenaga surya (photovoltaic), angin, nuklir. [Spesifikasi] 1. poles description : 1P 2. number of protected poles : 1 3. [In] rated current : 6 A at 25 C 4. network type : DC 5. trip unit technology : thermal-magnetic 6. curve code : C 7. breaking capacity : -Icu 10 kA at 220 V DC conforming to EN 60947-2 -Icu 10 kA at 220 V DC conforming to IEC 60947-2 -Icu 6 kA at 250 V DC conforming to EN 60947-2 -Icu 6 kA at 250 V DC conforming to IEC 60947-2 -Icu 20 kA at 110 V DC conforming to EN 60947-2 -Icu 20 kA at 110 V DC conforming to IEC 60947-2 8. utilization category : -Category A conforming to EN 60947-2 -Category A conforming to IEC 60947-2 9. suitability for isolation : -Yes conforming to EN 60947-2 -Yes conforming to IEC 60947-2 10. network frequency : 50/60 Hz 11. [Ue] rated operational voltage : 250 V DC 12. contact position indicator : Yes 13. control type : Toggle 14. local signaling : ON/OFF indication 15. mounting mode : Fixed 16. mounting support : 35 mm symmetrical DIN rail 17. comb busbar and distribution block compatibility : Standard top ot bottom 18. 9 mm pitches : 2 19. product weight : 0.128 kg 20. colour : White
Specifications for Schneider Acti 9 MCB C60H-DC 1P 6A DC
| # of Pole | 1 |
