Schneider Electric Domae RCBO Slim 1 Pole + N 30mA 6A - Kontrol Tegangan 230/240 V AC 50 Hz - DOM12520 [Deskripsi] RCBO adalah kombinasi antara MCB dan ELCB dalam satu produk dengan lebar yang sama yaitu 18 mm, sehingga hemat tempat dan lebih sederhana dari segi pemasangan. - Perlindungan terhadap bahaya sengatan listrik (ELCB 30mA) sekaligus bahan berlebih (MCB). - Ukuran yang slim, lebar 18mm sama seperti lebar MCB 1P, sangat cocok untuk penggantian MCB dan tambahan proteksi ELCB dengan tempat terbatas tanpa perlu mengganti box. - Hanya akan memutuskan bagian yang terdapat gangguan arus bocor. [Spesifikasi] 1. [In] rated current : 6 A ( 30 C ) 2. network type : AC 3. network type : 50 Hz 4. [Ue] rated operational voltage : 230/240 V AC 50 Hz 5. trip unit technology : Thermal-magnetic 6. curve code : C 7. magnetic tripping limit : 5...10 x In 8. earth-leakage sensitivity : 30 mA 9. earth-leakage protection time delay : Instantaneous 10. breaking capacity : Icn 4500 A at 230/240 V AC 50 Hz 11. electrical insulation class : Class II 12. limitation class : 3 13. [Ui] rated insulation voltage : 400 V AC 50 Hz 14. contact position indicator : Yes 15. control type : Toggle 16. local signalling : ON/OFF indication 17. mounting support : DIN rail 18. comb busbar and distribution block compatibility : YES 19. 9 mm pitches : 2 20. height : 93 mm 21. width : 18 mm 22. depth : 70 mm 23. product weight : 135 g 24. Colour : Grey
| range | Domae | |
|---|---|---|
| device application | Distribution | |
| product name | AD63 K | |
| product or component type | Residual current breaker with overcurrent protection (RCBO) | |
| poles description | 1P + N | |
| neutral position | Left | |
| earth-leakage protection class | Type AC | |
| suitability for isolation | Yes |
| [In] rated current | 6 A at 30 °C | |
|---|---|---|
| network type | AC | |
| network frequency | 50 Hz | |
| [Ue] rated operational voltage | 230/240 V AC 50 Hz | |
| trip unit technology | Thermal-magnetic | |
| curve code | C | |
| magnetic tripping limit | 5...10 x In | |
| earth-leakage sensitivity | 30 mA | |
| earth-leakage protection time delay | Instantaneous | |
| breaking capacity | 4500 A Icn at 230/240 V AC 50 Hz | |
| electrical insulation class | Class II | |
| limitation class | 3 | |
| [Ui] rated insulation voltage | 400 V AC 50 Hz | |
| contact position indicator | Yes | |
| control type | Toggle | |
| local signalling | ON/OFF indication | |
| mounting support | DIN rail | |
| comb busbar and distribution block compatibility | YES | |
| 9 mm pitches | 2 | |
| height | 93 mm | |
| width | 18 mm | |
| depth | 70 mm | |
| net weight | 136 g | |
| colour | Grey | |
| mechanical durability | 20000 cycles | |
| provision for padlocking | Padlockable | |
| locking options description | By padlocks | |
| connections - terminals | Screw clamp terminal (upstream) 1…16 mm² rigid Screw clamp terminal (upstream) 1…16 mm² flexible Screw clamp terminal (downstream) 1…10 mm² rigid Screw clamp terminal (downstream) 1…10 mm² flexible | |
| wire stripping length | 14 mm for upstream connection 11 mm for downstream connection | |
| tightening torque | 2 N.m upstream 2 N.m downstream | |
| earth-leakage protection | Integrated |
| standards | IEC 61009-1 IEC 61009-2-2 | |
|---|---|---|
| product certifications | SNI | |
| ambient air temperature for operation | -25…55 °C | |
| ambient air temperature for storage | -30…70 °C |
| Package 1 Weight | 130.000 g | |
|---|---|---|
| Package 1 Height | 18.000 mm | |
| Package 1 width | 72.000 mm | |
| Package 1 Length | 92.500 mm |
| Sustainable offer status | Green Premium product | |
|---|---|---|
| REACh Regulation | ||
| EU RoHS Directive | Compliant EU RoHS Declaration | |
| Mercury free | Yes | |
| RoHS exemption information | ||
| China RoHS Regulation | China RoHS declaration Product out of China RoHS scope. Substance declaration for your information | |
| Environmental Disclosure |
| Warranty | 12 months |
|---|
Specifications for Schneider Domae DOMAE RCBO SLIM 1P+N 6A 30MA 4,5KA
| # of Pole | 1 Pole + N |
| Arus Nominal (In) | 6A |
| earth-leakage sensitivity | 30mA |
