Spesifikasi
range | Domae | |
---|---|---|
product or component type | Residual current circuit breaker (RCCB) | |
device short name | RCCB | |
device application | Protection | |
poles description | 2P | |
earth-leakage protection class | Type AC | |
suitability for isolation | Yes |
neutral position | Left | |
---|---|---|
[In] rated current | 63 A | |
network type | AC | |
network frequency | 50 Hz | |
[Ue] rated operational voltage | 230 V AC 50 Hz | |
earth-leakage sensitivity | 300 mA | |
earth-leakage protection time delay | Instantaneous | |
rated breaking and making capacity | 3000 A | |
rated conditional short-circuit current | Fuse: 6000 A | |
[Ui] rated insulation voltage | 440 V AC 50 Hz | |
[Uimp] rated impulse withstand voltage | 4 kV | |
surge current | 250 A | |
control type | Toggle | |
local signalling | ON/OFF indication | |
mounting mode | Clip-on | |
mounting support | DIN rail | |
comb busbar and distribution block compatibility | YES | |
9 mm pitches | 4 | |
height | 81 mm | |
width | 36 mm | |
depth | 76 mm | |
embedding depth | 44 mm | |
net weight | 180 kg | |
colour | White | |
mechanical durability | 5000 cycles | |
electrical durability | 2000 cycles | |
connections - terminals | Tunnel type terminals (top or bottom) 1…35 mm² rigid Tunnel type terminals (top or bottom) 1…25 mm² flexible | |
wire stripping length | 14 mm | |
tightening torque | 3.5 N.m |
standards | IEC 61008-1 | |
---|---|---|
product certifications | SNI | |
IP degree of protection | IP20 conforming to IEC 60529 IP40 (modular enclosure) conforming to IEC 60529 | |
pollution degree | 2 | |
overvoltage category | III | |
tropicalisation | 2 conforming to IEC 60068-1 | |
relative humidity | 95 % at 55 °C | |
ambient air temperature for operation | -5…40 °C | |
ambient air temperature for storage | -40…60 °C |
REACh Regulation | ||
---|---|---|
EU RoHS Directive | Compliant EU RoHS Declaration | |
Mercury free | Yes | |
RoHS exemption information | ||
China RoHS Regulation | China RoHS declaration Product out of China RoHS scope. Substance declaration for your information | |
WEEE | The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins |
