  4. Schneider Easypact EZC Schneider Electric Easypact EZC MCCB EZC100H TMD - 40 A - 3P/3d - EZC100H3040

Schneider Easypact EZC Schneider Electric Easypact EZC MCCB EZC100H TMD - 40 A - 3P/3d - EZC100H3040

# of Pole : 3

Trip Unit Rating : 40 A at 50 °C

Rp 1,622,342.00 Rp 843,617.00 843617 IDR

Rp 1,622,342.00

Option not available

  • # of Pole
  • Trip Unit Rating

This combination does not exist.

Add to Cart

Schneider Easypact EZC Schneider Electric Easypact EZC MCCB EZC100H TMD - 40 A - 3P/3d - EZC100H3040
Terjual 0
0 (0 Rating)
Ulasan (0)

Rp 843,617.00
48.00 % Rp 1,622,342.00 843617 IDR

Rp 1,622,342.00

Option not available

Atur Jumlah & Catatan
Stock Total: 14

# of Pole : 3

Trip Unit Rating : 40 A at 50 °C

Keranjang Beli Sekarang
Spesifikasi

Schneider Electric MCCB EasyPact EZC - 40 A - 3P/3d - EZC100H3040 [Deskripsi] -Aplikasi untuk instalasi listrik dengan kapasitas pemutusan rendah. -Kapasitas Pemutusan : 7.5 kA s/d 30 kA pada 380/415 VAC. -Thermal magnetic trip unit, tidak dapat disetel (non adjustable). -Fixed type, front connection. -Satu ukuran (frame size) untuk semua rating. -Memenuhi standar IEC 60947-2. -Rated @ 125V DC (1P) dan @ 250V DC (2P in series) [Spesifikasi] 1. poles description : 3P 2. protected poles description : 3t 3. network type : -DC -AC 4. network frequency : 50/60 Hz 5. [In] rated current : 100 A at 40 °C 6. [Ui] rated insulation voltage : 690 V AC 50/60 Hz conforming to IEC 60947-2 7. [Uimp] rated impulse withstand voltage : 6 kV conforming to IEC 60947-2 8. [Ue] rated operational voltage : -550 V AC 50/60 Hz conforming to IEC 60947-2 -250 V DC conforming to IEC 60947-2 9. control type : Toggle 10. mounting mode : Fixed 11. mounting support : Backplate 12. upside connection : Front 13. downside connection : Front 14. mechanical durability : 8500 cycles 15. electrical durability : Category A : 1500 cycles 415 V AC 50/60 Hz conforming to IEC 60947-2 16. connection pitch : 25 mm 17. local signalling : Positive contact indication 18. neutral protection setting : Without protection 19. earth-leakage protection : Without 20. height : 130 mm 21. width : 75 mm 22. depth : 60 mm


  • Main (see above)
    range of product
    EasyPact
    product or component type
    Circuit breaker
    device short name
    Easypact EZC100H
    circuit breaker name
    Easypact EZC100H
    device application
    Distribution
    poles description
    3P
    protected poles description
    3t
    network type
    AC
    DC
    network frequency
    50/60 Hz
    [In] rated current
    100 A at 40 °C
    [Ui] rated insulation voltage
    690 V AC 50/60 Hz conforming to IEC 60947-2
    [Uimp] rated impulse withstand voltage
    6 kV conforming to IEC 60947-2
    [Ue] rated operational voltage
    550 V AC 50/60 Hz conforming to IEC 60947-2
    250 V DC conforming to IEC 60947-2
    breaking capacity code
    H
    breaking capacity
    10 kA Icu at 125 V DC 1P conforming to IEC 60947-2
    10 kA Icu at 250 V DC 2P conforming to IEC 60947-2
    10 kA Icu at 550 V AC 50/60 Hz conforming to IEC 60947-2
    100 kA Icu at 110...130 V AC 50/60 Hz conforming to IEC 60947-2
    100 kA Icu at 220...240 V AC 50/60 Hz conforming to IEC 60947-2
    20 kA Icu at 440 V AC 50/60 Hz conforming to IEC 60947-2
    30 kA Icu at 380 V AC 50/60 Hz conforming to IEC 60947-2
    30 kA Icu at 400...415 V AC 50/60 Hz conforming to IEC 60947-2
    [Ics] rated service breaking capacity
    15 kA at 380 V AC 50/60 Hz conforming to IEC 60947-2
    5 kA at 125 V DC conforming to IEC 60947-2
    5 kA at 250 V DC conforming to IEC 60947-2
    50 kA at 110/130 V AC 50/60 Hz conforming to IEC 60947-2
    50 kA at 220/230/240 V AC 50/60 Hz conforming to IEC 60947-2
    5 kA at 440 V AC 50/60 Hz conforming to IEC 60947-2
    2.5 kA at 550 V AC 50/60 Hz conforming to IEC 60947-2
    7.5 kA at 400/415 V AC 50/60 Hz conforming to IEC 60947-2
    suitability for isolation
    Yes conforming to IEC 60947-2
    utilisation category
    Category A
    trip unit name
    TM-D
    trip unit technology
    Thermal-magnetic
    trip unit rating
    40 A at 50 °C
    protection type
    Overload protection
    Short-circuit protection
    pollution degree
    3 conforming to IEC 60664-1
    3 conforming to IEC 947-1
    Complementary (see above)
    control type
    Toggle
    mounting mode
    Fixed
    mounting support
    Backplate
    upside connection
    Front
    downside connection
    Front
    mechanical durability
    8500 cycles
    electrical durability
    Category A: 1500 cycles 415 V AC 50/60 Hz conforming to IEC 60947-2
    connection pitch
    25 mm
    local signalling
    Positive contact indication
    neutral protection setting
    Without protection
    earth-leakage protection
    Without
    height
    130 mm
    width
    75 mm
    depth
    60 mm
    Environment (see above)
    standards
    JIS C8201-2-2
    EN/IEC 60947-1
    EN/IEC 60947-2
    GB/T 14048.2
    IP degree of protection
    IP20 conforming to IEC 60529
    IK degree of protection
    IK07 conforming to IEC 62262
    ambient air temperature for operation
    -25…70 °C
    ambient air temperature for storage
    -35…85 °C
    Packing Units (see above)
    Unit Type of Package 1
    PCE
    Number of Units in Package 1
    1
    Package 1 Weight
    790 g
    Package 1 Height
    9.5 cm
    Package 1 width
    8.5 cm
    Package 1 Length
    14 cm
    Unit Type of Package 2
    S02
    Number of Units in Package 2
    12
    Package 2 Weight
    9.848 kg
    Package 2 Height
    15 cm
    Package 2 width
    30 cm
    Package 2 Length
    40 cm
    Unit Type of Package 3
    P06
    Number of Units in Package 3
    192
    Package 3 Weight
    173.412 kg
    Package 3 Height
    80 cm
    Package 3 width
    80 cm
    Package 3 Length
    60 cm
    Offer Sustainability (see above)
    Sustainable offer status
    Green Premium product
    REACh Regulation
    REACh free of SVHC
    Yes
    EU RoHS Directive
    Toxic heavy metal free
    Yes
    Mercury free
    Yes
    RoHS exemption information
    China RoHS Regulation
    Environmental Disclosure
    WEEE
    The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins
    Contractual warranty (see above)
    Warranty
    12 months

Specifications for Schneider Easypact EZC Schneider Electric Easypact EZC MCCB EZC100H TMD - 40 A - 3P/3d - EZC100H3040

# of Pole 3
Trip Unit Rating 40 A at 50 °C
