  4. Schneider CVS100N 3P 16A - TM16D 3P3D circuit breaker

Schneider CVS100N 3P 16A - TM16D 3P3D circuit breaker

Rp 2,743,920.00 Rp 1,426,838.00 1426838 IDR

Rp 2,743,920.00

Option not available

    This combination does not exist.

    Add to Cart

    Schneider CVS100N 3P 16A - TM16D 3P3D circuit breaker
    Terjual 0
    0 (0 Rating)
    Ulasan (0)

    Rp 1,426,838.00
    48.00 % Rp 2,743,920.00 1426838 IDR

    Rp 2,743,920.00

    Option not available

    Atur Jumlah & Catatan
    Stock Total: 15
    Keranjang Beli Sekarang
    Spesifikasi
    Main (see above)
    range of product
    Easypact CVS100...250
    product or component type
    Circuit breaker
    device short name
    CVS100N
    device application
    Distribution
    poles description
    3P
    protected poles description
    3d
    Earth leakage protection (Vigi add on)
    Without
    [In] rated current
    100 A at 40 °C
    breaking capacity code
    N
    network type
    AC
    [Icu] Breaking capacity
    50 kA Icu at 380/415 V AC 50/60 Hz conforming to IEC 60947-2
    40 kA Icu at 440 V AC 50/60 Hz conforming to IEC 60947-2
    80 kA Icu at 220/240 V AC 50/60 Hz conforming to IEC 60947-2
    utilisation category
    Category A
    trip unit name
    TM-D
    trip unit technology
    Thermal-magnetic
    trip unit rating
    16 A at 40 °C
    protection type
    Short-circuit protection (magnetic)
    Overload protection (thermal)
    Complementary (see above)
    network frequency
    50/60 Hz
    control type
    Toggle
    mounting mode
    Fixed
    mounting support
    Backplate
    upside connection
    Front
    downside connection
    Front
    connections - terminals
    Screw connection
    [Uimp] rated impulse withstand voltage
    8 kV conforming to EN/IEC 60947-2
    thermal protection adjustment range
    0…16 A
    [Ics] rated service breaking capacity
    30 kA at 440 V AC 50/60 Hz conforming to IEC 60947-2
    50 kA at 380/415 V AC 50/60 Hz conforming to IEC 60947-2
    80 kA at 220/240 V AC 50/60 Hz conforming to IEC 60947-2
    mechanical durability
    30000 cycles
    electrical durability
    12000 cycles 415 V In conforming to IEC 60947-2
    connection pitch
    35 mm
    contact position indicator
    Yes
    long time pick-up adjustment type Ir
    Adjustable
    long time pick-up adjustment range
    0.7...1 x In
    long time delay adjustment type
    Fixed
    short-time delay adjustment type
    Fixed
    instantaneous pick-up adjustment type Ii
    Fixed
    instantaneous pick-up adjustment range
    190 A
    height
    161 mm
    width
    105 mm
    depth
    86 mm
    Environment (see above)
    electrical shock protection class
    Class II
    standards
    IEC 60947-2
    EN 60947-2
    product certifications
    GOST
    IEC
    IP degree of protection
    IP40
    ambient air temperature for operation
    -25…70 °C
    ambient air temperature for storage
    -50…85 °C
    Packing Units (see above)
    Unit Type of Package 1
    PCE
    Number of Units in Package 1
    1
    Package 1 Weight
    1.822 kg
    Package 1 Height
    110.94 mm
    Package 1 width
    136.95 mm
    Package 1 Length
    188.84 mm
    Offer Sustainability (see above)
    Sustainable offer status
    Green Premium product
    REACh Regulation
    EU RoHS Directive
    Mercury free
    Yes
    RoHS exemption information
    China RoHS Regulation
    China RoHS declaration
    Product out of China RoHS scope. Substance declaration for your information
    Environmental Disclosure
    Circularity Profile
    WEEE
    The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins
    Contractual warranty (see above)
    Warranty
    12 months
