  5. Schneider TeSys F - specific contactor coil - 220...230 V AC 40...400 Hz low consumption

Schneider TeSys F - specific contactor coil - 220...230 V AC 40...400 Hz low consumption

Rp 2,525,549.00 Rp 1,515,329.00 1515329 IDR

Rp 2,525,549.00

Option not available

    This combination does not exist.

    Add to Cart

    Schneider TeSys F - specific contactor coil - 220...230 V AC 40...400 Hz low consumption
    Terjual 0
    0 (0 Rating)
    Ulasan (0)

    Rp 1,515,329.00
    40.00 % Rp 2,525,549.00 1515329 IDR

    Rp 2,525,549.00

    Option not available

    Atur Jumlah & Catatan
    Stock Total: 18
    Keranjang Beli Sekarang
    Spesifikasi

    [Deskripsi] TeSys F adalah rangkaian kontaktor arus tinggi dari 115 A hingga 1000 A yang dirancang untuk aplikasi AC-3 dan dari 200 A hingga 2600 A untuk aplikasi AC-1. [Spesifikasi] 1. circuit type : AC at 40...400 Hz low consumption 2. [Uc] control circuit voltage : 220...230 V AC 40...400 Hz 3. average resistance : -1680 Ohm holding at 20 °C -42.1 Ohm inrush at 20 °C 4. operating time : -130 ms opening -35 ms closing 5. mechanical durability : 10 Mcycles 6. maximum operating rate : 2400 cyc/h 55 °C 7. coil technology : Without built-in suppressor module 8. control circuit voltage limits : -Operational: 0.85...1.1 Uc (at 55 °C) -Drop-out: 0.35...0.55 Uc (at 55 °C) 9. inrush power in VA : 950…1180 VA 40...400 Hz (at 20 °C) 10. hold-in power consumption in VA : 8.9…10.9 VA 40...400 Hz (at 20 °C) 11. heat dissipation : 8…9.8 W 12. ambient air temperature for operation : -5…55 °C 13. net weight : 0.55 kg 14. inductance of closed circuit : 5.84 H


    Main (see above)
    range
    TeSys
    product or component type
    Specific contactor coil
    device short name
    LX9FG
    range compatibility
    TeSys F LC1F contactor
    product compatibility
    LC1F225
    LC1F185
    control circuit type
    AC at 40...400 Hz low consumption
    [Uc] control circuit voltage
    220...230 V AC 40...400 Hz
    average resistance
    1680 Ohm holding at 20 °C
    42.1 Ohm inrush at 20 °C
    inductance of closed circuit
    5.84 H
    operating time
    130 ms opening
    35 ms closing
    mechanical durability
    10 Mcycles
    maximum operating rate
    2400 cyc/h 55 °C
    Complementary (see above)
    coil technology
    Without built-in suppressor module
    control circuit voltage limits
    Operational: 0.85...1.1 Uc (at 55 °C)
    Drop-out: 0.35...0.55 Uc (at 55 °C)
    inrush power in VA
    950…1180 VA 40...400 Hz (at 20 °C)
    hold-in power consumption in VA
    8.9…10.9 VA 40...400 Hz (at 20 °C)
    heat dissipation
    8…9.8 W
    Environment (see above)
    ambient air temperature for operation
    -5…55 °C
    net weight
    0.55 kg
    Packing Units (see above)
    Unit Type of Package 1
    PCE
    Number of Units in Package 1
    1
    Package 1 Weight
    581 g
    Package 1 Height
    7.5 cm
    Package 1 width
    10.5 cm
    Package 1 Length
    17.7 cm
    Unit Type of Package 2
    S03
    Number of Units in Package 2
    14
    Package 2 Weight
    8.44 kg
    Package 2 Height
    30 cm
    Package 2 width
    30 cm
    Package 2 Length
    40 cm
    Offer Sustainability (see above)
    Sustainable offer status
    Green Premium product
    REACh Regulation
    REACh free of SVHC
    Yes
    EU RoHS Directive
    Pro-active compliance (Product out of EU RoHS legal scope)
    EU RoHS Declaration
    Mercury free
    Yes
    RoHS exemption information
    China RoHS Regulation
    Environmental Disclosure
    Circularity Profile
    Contractual warranty (see above)
    Warranty
    12 months
