  4. Schneider Linergy passthrough terminal block - 4mm2 32A single-level 1x1 screw - grey

Schneider Linergy passthrough terminal block - 4mm2 32A single-level 1x1 screw - grey

Rp 25,641.00 Rp 13,589.00 13589 IDR

Rp 25,641.00

Option not available

    This combination does not exist.

    Add to Cart

    Schneider Linergy passthrough terminal block - 4mm2 32A single-level 1x1 screw - grey
    Terjual 0
    0 (0 Rating)
    Ulasan (0)

    Rp 13,589.00
    47.00 % Rp 25,641.00 13589 IDR

    Rp 25,641.00

    Option not available

    Atur Jumlah & Catatan
    Stock Total: 2099
    Keranjang Beli Sekarang
    Spesifikasi
    Main (see above)
    range
    Linergy

    product name
    Linergy TR

    product or component type
    Terminal block

    device short name
    TRV

    accessory / separate part category
    Connection accessory

    terminal block type
    Passthrough

    terminal block level
    1

    mounting mode
    Clip-on

    nominal cross section
    4 mm²

    length
    47.7 mm

    colour
    Grey

    quantity per set
    Set of 50

    Complementary (see above)
    width
    6.2 mm

    height
    47.5 mm

    connections - terminals
    1 x screw terminal: upstream (M3)
    1 x screw terminal: downstream (M3)

    number of connections
    2

    connection position
    Sideways

    number of measurement input
    2

    cable cross section
    0.14…6 mm², solid cable with cable end
    0.2…4 mm², flexible cable with cable end
    0.2…6 mm², solid cable without cable end
    0.2…6 mm², flexible cable without cable end

    tightening torque
    0.6…0.8 N.m

    wire stripping length
    9 mm

    tool type
    Connection: screwdriver
    Disconnection: screwdriver

    [Ue] rated operational voltage
    1000 V conforming to EN/IEC 60947-7-1
    600 V CSA
    690 V conforming to ATEX Exe II Ex II 2 GD
    600 V cURus

    [In] rated current
    32 A conforming to EN/IEC 60947-7-1
    30 A CSA
    30 A conforming to ATEX Exe II Ex II 2 GD
    30 A cURus

    material
    Polyamide 6/6: insulating case
    Copper alloy: connector and screw
    Copper alloy: commoning link
    Chromium-nickel steel: spring

    dielectric loss
    0.01 at 1 MHz conforming to IEC 60250
    0.01 at 1 MHz conforming to VDE 0303-T4

    dielectric constant
    3.7 at 1 MHz

    resistivity
    10000 MΩ.m conforming to IEC 60093
    10000 MΩ.m conforming to VDE 0303-T30

    surface resistance
    1000 GΩ conforming to IEC 60093
    1000 GΩ conforming to VDE 0303-T30

    creep resistance
    500 CTI (> 400 kB) conforming to IEC 60093
    500 CTI (> 400 kB) conforming to VDE 0303-T30

    flame retardance
    V0, thickness0.8 mm conforming to UL 94

    net weight
    9.4 g

    range compatibility
    Prisma G
    Prisma P
    Prisma PH
    Prisma Pack
    Spacial
    Kaedra
    Pragma
    TeSys

    product compatibility
    Spacial enclosures

    Environment (see above)
    product certifications
    CURus
    VDE
    IEC-Ex
    ATEX
    GL
    EAC
    LR
    CSA
    DNV

    dielectric strength
    1000 V conforming to IEC 60243-1

    ambient air temperature for operation
    -40…130 °C conforming to IEC 60216-1
    -40…130 °C conforming to VDE 0304-T21

    Packing Units (see above)
    Unit Type of Package 1
    PCE

    Number of Units in Package 1
    1

    Package 1 Weight
    8.8 g

    Package 1 Height
    4.8 cm

    Package 1 width
    0.6 cm

    Package 1 Length
    4.7 cm

    Unit Type of Package 2
    CAR

    Number of Units in Package 2
    50

    Package 2 Weight
    482 g

    Package 2 Height
    5.2 cm

    Package 2 width
    7.8 cm

    Package 2 Length
    24.5 cm

    Unit Type of Package 3
    BB1

    Number of Units in Package 3
    50

    Package 3 Weight
    482 g

    Package 3 Height
    5.2 cm

    Package 3 width
    7.8 cm

    Package 3 Length
    24.5 cm

    Offer Sustainability (see above)
    Sustainable offer status
    Green Premium product

    REACh Regulation
    EU RoHS Directive
    Mercury free
    Yes

    RoHS exemption information
    China RoHS Regulation
    China RoHS declaration
    Product out of China RoHS scope. Substance declaration for your information

    Environmental Disclosure
    WEEE
    The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins

    Halogen content performance
    Halogen free plastic parts product

    Contractual warranty (see above)
    Warranty
    12 months
