  4. Schneider Socket RPZ - mixed contact - 16 A - < 250 V - screw clamp - for relay RPM4

Schneider Socket RPZ - mixed contact - 16 A - < 250 V - screw clamp - for relay RPM4

Rp 133.200,00 Rp 75.924,00 75924 IDR

Rp 133.200,00

Option not available

    This combination does not exist.

    Add to Cart

    Schneider Socket RPZ - mixed contact - 16 A - < 250 V - screw clamp - for relay RPM4
    Terjual 0
    0 (0 Rating)
    Ulasan (0)

    Rp 75.924,00
    43.00 % Rp 133.200,00 75924 IDR

    Rp 133.200,00

    Option not available

    Atur Jumlah & Catatan
    Stock Total: 185
    Keranjang Beli Sekarang
    Spesifikasi
    Main (see above)
    range of product
    Harmony Electromechanical Relays
    product or component type
    Socket
    contact terminal arrangement
    Mixed
    product compatibility
    Plug-in relay RPM with 4 C/O contact
    shape of pin
    Flat
    device short name
    RPZ
    sale per indivisible quantity
    10
    Complementary (see above)
    [Ith] conventional free air thermal current
    16 A
    [Ue] rated operational voltage
    < 250 V
    tightening torque
    < 1 N.m for M3.5 screw(s)
    fixing mode
    By screw (panel)
    Clip-on (35 mm symmetrical DIN rail)
    marking
    CE
    width
    50 mm
    net weight
    0.094 kg
    Environment (see above)
    connections - terminals
    - screw clamp terminals, flexible cable with cable end 1 x 0.5...1 x 2.5 mm² / AWG 20...AWG 14
    - screw clamp terminals, solid cable without cable end 1 x 0.5...1 x 1.5 mm² / AWG 20...AWG 16
    - screw clamp terminals, flexible cable with cable end 2 x 0.5...2 x 2.5 mm² / AWG 20...AWG 14
    - screw clamp terminals, solid cable without cable end 2 x 0.5...2 x 1.5 mm² / AWG 20...AWG 16
    standards
    IEC 61984
    product certifications
    UL
    CSA
    ambient air temperature for storage
    -40…85 °C
    ambient air temperature for operation
    -40…55 °C
    IP degree of protection
    IP20 conforming to EN/IEC 60529
    dielectric strength
    2500 V
    Packing Units (see above)
    Unit Type of Package 1
    PCE
    Number of Units in Package 1
    1
    Package 1 Weight
    101 g
    Package 1 Height
    29.94 mm
    Package 1 width
    50.3 mm
    Package 1 Length
    83.79 mm
    Unit Type of Package 2
    BB1
    Number of Units in Package 2
    10
    Package 2 Weight
    1.01 kg
    Package 2 Height
    6.4 cm
    Package 2 width
    8.5 cm
    Package 2 Length
    25.4 cm
    Unit Type of Package 3
    S03
    Number of Units in Package 3
    110
    Package 3 Weight
    11.898 kg
    Package 3 Height
    30 cm
    Package 3 width
    30 cm
    Package 3 Length
    40 cm
    Offer Sustainability (see above)
    Sustainable offer status
    Green Premium product
    REACh Regulation
    REACh free of SVHC
    Yes
    EU RoHS Directive
    Pro-active compliance (Product out of EU RoHS legal scope)
    EU RoHS Declaration
    Toxic heavy metal free
    Yes
    Mercury free
    Yes
    RoHS exemption information
    China RoHS Regulation
    Environmental Disclosure
    WEEE
    The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins
    California proposition 65
    WARNING: This product can expose you to chemicals including: Nickel compounds, which is known to the State of California to cause cancer, and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
    Contractual warranty (see above)
    Warranty
    12 months
