Spesifikasi
range of product | Harmony XB4 | |
---|---|---|
product or component type | Pilot light | |
device short name | XB4 | |
bezel material | Chromium plated metal | |
fixing collar material | Zamak | |
mounting diameter | 22 mm | |
head type | Standard | |
sale per indivisible quantity | 1 | |
shape of signaling unit head | Round | |
cap/operator or lens colour | Green | |
operator additional information | With plain lens | |
light source | Protected LED | |
bulb base | Integral LED | |
light source colour | Green | |
[Us] rated supply voltage | 230...240 V AC 50/60 Hz |
height | 47 mm | |
---|---|---|
width | 30 mm | |
depth | 54 mm | |
terminals description ISO n°1 | (X1-X2)PL | |
net weight | 0.08 kg | |
resistance to high pressure washer | 7000000 Pa at 55 °C, distance : 0.1 m | |
connections - terminals | Screw clamp terminals, <= 2 x 1.5 mm² with cable end conforming to EN/IEC 60947-1 Screw clamp terminals, 1 x 0.22...2 x 2.5 mm² without cable end conforming to EN/IEC 60947-1 | |
[Ui] rated insulation voltage | 250 V (pollution degree 3) conforming to EN 60947-1 | |
[Uimp] rated impulse withstand voltage | EN 60947-1 4 kV | |
signalling type | Steady | |
current consumption | 14 mA | |
service life | 100000 h at rated voltage and 25 °C | |
surge withstand | 1 kV conforming to IEC 61000-4-5 | |
device presentation | Complete product | |
supply voltage limits | 195…264 V AC |
protective treatment | TH | |
---|---|---|
ambient air temperature for storage | -40…70 °C | |
ambient air temperature for operation | -40…70 °C | |
electrical shock protection class | Class I conforming to IEC 60536 | |
IP degree of protection | IP66 conforming to IEC 60529 IP67 IP69 IP69K | |
NEMA degree of protection | NEMA 13 NEMA 4X | |
IK degree of protection | IK06 conforming to IEC 50102 | |
standards | JIS C8201-5-1 CSA C22.2 No 14 EN/IEC 60947-5-5 EN/IEC 60947-5-1 UL 508 EN/IEC 60947-5-4 EN/IEC 60947-1 JIS C8201-1 | |
product certifications | CSA UL listed | |
vibration resistance | 5 gn (f= 12…500 Hz) conforming to IEC 60068-2-6 | |
shock resistance | 30 gn (duration = 18 ms) for half sine wave acceleration conforming to IEC 60068-2-27 50 gn (duration = 11 ms) for half sine wave acceleration conforming to IEC 60068-2-27 | |
resistance to fast transients | 2 kV conforming to IEC 61000-4-4 | |
resistance to electromagnetic fields | 10 V/m conforming to IEC 61000-4-3 | |
resistance to electrostatic discharge | 6 kV on contact (on metal parts) conforming to IEC 61000-4-2 8 kV in free air (in insulating parts) conforming to IEC 61000-4-2 | |
electromagnetic emission | Class B conforming to IEC 55011 |
Unit Type of Package 1 | PCE | |
---|---|---|
Number of Units in Package 1 | 1 | |
Package 1 Weight | 80 g | |
Package 1 Height | 3.4 cm | |
Package 1 width | 5.4 cm | |
Package 1 Length | 8.8 cm | |
Unit Type of Package 2 | BB1 | |
Number of Units in Package 2 | 5 | |
Package 2 Weight | 402 g | |
Package 2 Height | 3.4 cm | |
Package 2 width | 8.8 cm | |
Package 2 Length | 26.5 cm | |
Unit Type of Package 3 | S03 | |
Number of Units in Package 3 | 150 | |
Package 3 Weight | 12.476 kg | |
Package 3 Height | 30 cm | |
Package 3 width | 30 cm | |
Package 3 Length | 40 cm |
Sustainable offer status | Green Premium product | |
---|---|---|
REACh Regulation | ||
REACh free of SVHC | Yes | |
EU RoHS Directive | Pro-active compliance (Product out of EU RoHS legal scope) EU RoHS Declaration | |
Mercury free | Yes | |
RoHS exemption information | ||
China RoHS Regulation | ||
Environmental Disclosure | ||
Circularity Profile | ||
WEEE | The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins |
Warranty | 12 months |
---|
range of product | Harmony XB4 | |
---|---|---|
product or component type | Pilot light | |
device short name | XB4 | |
bezel material | Chromium plated metal | |
fixing collar material | Zamak | |
mounting diameter | 22 mm | |
head type | Standard | |
sale per indivisible quantity | 1 | |
shape of signaling unit head | Round | |
cap/operator or lens colour | Green | |
operator additional information | With plain lens | |
light source | Protected LED | |
bulb base | Integral LED | |
light source colour | Green | |
[Us] rated supply voltage | 230...240 V AC 50/60 Hz |
height | 47 mm | |
---|---|---|
width | 30 mm | |
depth | 54 mm | |
terminals description ISO n°1 | (X1-X2)PL | |
net weight | 0.08 kg | |
resistance to high pressure washer | 7000000 Pa at 55 °C, distance : 0.1 m | |
connections - terminals | Screw clamp terminals, <= 2 x 1.5 mm² with cable end conforming to EN/IEC 60947-1 Screw clamp terminals, 1 x 0.22...2 x 2.5 mm² without cable end conforming to EN/IEC 60947-1 | |
[Ui] rated insulation voltage | 250 V (pollution degree 3) conforming to EN 60947-1 | |
[Uimp] rated impulse withstand voltage | EN 60947-1 4 kV | |
signalling type | Steady | |
current consumption | 14 mA | |
service life | 100000 h at rated voltage and 25 °C | |
surge withstand | 1 kV conforming to IEC 61000-4-5 | |
device presentation | Complete product | |
supply voltage limits | 195…264 V AC |
protective treatment | TH | |
---|---|---|
ambient air temperature for storage | -40…70 °C | |
ambient air temperature for operation | -40…70 °C | |
electrical shock protection class | Class I conforming to IEC 60536 | |
IP degree of protection | IP66 conforming to IEC 60529 IP67 IP69 IP69K | |
NEMA degree of protection | NEMA 13 NEMA 4X | |
IK degree of protection | IK06 conforming to IEC 50102 | |
standards | JIS C8201-5-1 CSA C22.2 No 14 EN/IEC 60947-5-5 EN/IEC 60947-5-1 UL 508 EN/IEC 60947-5-4 EN/IEC 60947-1 JIS C8201-1 | |
product certifications | CSA UL listed | |
vibration resistance | 5 gn (f= 12…500 Hz) conforming to IEC 60068-2-6 | |
shock resistance | 30 gn (duration = 18 ms) for half sine wave acceleration conforming to IEC 60068-2-27 50 gn (duration = 11 ms) for half sine wave acceleration conforming to IEC 60068-2-27 | |
resistance to fast transients | 2 kV conforming to IEC 61000-4-4 | |
resistance to electromagnetic fields | 10 V/m conforming to IEC 61000-4-3 | |
resistance to electrostatic discharge | 6 kV on contact (on metal parts) conforming to IEC 61000-4-2 8 kV in free air (in insulating parts) conforming to IEC 61000-4-2 | |
electromagnetic emission | Class B conforming to IEC 55011 |
Unit Type of Package 1 | PCE | |
---|---|---|
Number of Units in Package 1 | 1 | |
Package 1 Weight | 80 g | |
Package 1 Height | 3.4 cm | |
Package 1 width | 5.4 cm | |
Package 1 Length | 8.8 cm | |
Unit Type of Package 2 | BB1 | |
Number of Units in Package 2 | 5 | |
Package 2 Weight | 402 g | |
Package 2 Height | 3.4 cm | |
Package 2 width | 8.8 cm | |
Package 2 Length | 26.5 cm | |
Unit Type of Package 3 | S03 | |
Number of Units in Package 3 | 150 | |
Package 3 Weight | 12.476 kg | |
Package 3 Height | 30 cm | |
Package 3 width | 30 cm | |
Package 3 Length | 40 cm |
Sustainable offer status | Green Premium product | |
---|---|---|
REACh Regulation | ||
REACh free of SVHC | Yes | |
EU RoHS Directive | Pro-active compliance (Product out of EU RoHS legal scope) EU RoHS Declaration | |
Mercury free | Yes | |
RoHS exemption information | ||
China RoHS Regulation | ||
Environmental Disclosure | ||
Circularity Profile | ||
WEEE | The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins |
Warranty | 12 months |
---|
Recently Viewed Products
Schneider Green complete pilot light (D)22 plain lens with integral LED 230.240V
