  2. Signalling
  3. Push Button dan XA2 Series
  4. Schneider Blue flush complete illum pushbutton (D)22 spring return 1NO+1NC 110...120V

Schneider Blue flush complete illum pushbutton (D)22 spring return 1NO+1NC 110...120V

Rp 436,168.00 Rp 252,977.00 252977 IDR

Rp 436,168.00

Option not available

    This combination does not exist.

    Add to Cart

    Schneider Blue flush complete illum pushbutton (D)22 spring return 1NO+1NC 110...120V
    Terjual 0
    0 (0 Rating)
    Ulasan (0)

    Rp 252,977.00
    42.00 % Rp 436,168.00 252977 IDR

    Rp 436,168.00

    Option not available

    Atur Jumlah & Catatan
    Stock Total: 2
    Keranjang Beli Sekarang
    Spesifikasi
    Main (see above)
    range of productHarmony XB4
    product or component typeIlluminated push-button
    device short nameXB4
    bezel materialChromium plated metal
    fixing collar materialZamak
    mounting diameter22 mm
    sale per indivisible quantity1
    head typeStandard
    shape of signaling unit headRound
    type of operatorSpring return
    operator profileBlue flush
    operator additional informationWith plain lens
    contacts type and composition1 NO + 1 NC
    contact operationSlow-break
    connections - terminalsScrew clamp terminals, <= 2 x 1.5 mm² with cable end conforming to EN/IEC 60947-1
    Screw clamp terminals, 1 x 0.22...2 x 2.5 mm² without cable end conforming to EN/IEC 60947-1
    light sourceProtected LED
    bulb baseIntegral LED
    [Us] rated supply voltage110...120 V AC at 50/60 Hz
    Complementary (see above)
    height47 mm
    width30 mm
    depth101 mm
    terminals description ISO n°1(21-22)NC
    (13-14)NO
    net weight0.097 kg
    resistance to high pressure washer7000000 Pa at 55 °C, distance : 0.1 m
    contacts usageStandard contacts
    positive openingWith conforming to EN/IEC 60947-5-1 appendix K
    operating travel1.5 mm (NC changing electrical state)
    2.6 mm (NO changing electrical state)
    4.3 mm (total travel)
    operating force3.5 N NC changing electrical state
    3.8 N
    mechanical durability10000000 cycles
    tightening torque0.8…1.2 N.m conforming to EN 60947-1
    shape of screw headCross compatible with Philips no 1 screwdriver
    Cross compatible with pozidriv No 1 screwdriver
    Slotted compatible with flat Ø 4 mm screwdriver
    Slotted compatible with flat Ø 5.5 mm screwdriver
    contacts materialSilver alloy (Ag/Ni)
    short-circuit protection10 A cartridge fuse type gG conforming to EN/IEC 60947-5-1
    [Ith] conventional free air thermal current10 A conforming to EN/IEC 60947-5-1
    [Ui] rated insulation voltage600 V (pollution degree 3) conforming to EN/IEC 60947-1
    [Uimp] rated impulse withstand voltageEN/IEC 60947-1 6 kV
    [Ie] rated operational current3 A at 240 V, AC-15, A600 conforming to EN/IEC 60947-5-1
    6 A at 120 V, AC-15, A600 conforming to EN/IEC 60947-5-1
    0.1 A at 600 V, DC-13, Q600 conforming to EN/IEC 60947-5-1
    0.27 A at 250 V, DC-13, Q600 conforming to EN/IEC 60947-5-1
    0.55 A at 125 V, DC-13, Q600 conforming to EN/IEC 60947-5-1
    1.2 A at 600 V, AC-15, A600 conforming to EN/IEC 60947-5-1
    electrical durability1000000 cycles, AC-15, 2 A at 230 V, operating rate <3600 cyc/h, load factor: 0.5 conforming to EN/IEC 60947-5-1 appendix C
    1000000 cycles, AC-15, 3 A at 120 V, operating rate <3600 cyc/h, load factor: 0.5 conforming to EN/IEC 60947-5-1 appendix C
    1000000 cycles, AC-15, 4 A at 24 V, operating rate <3600 cyc/h, load factor: 0.5 conforming to EN/IEC 60947-5-1 appendix C
    1000000 cycles, DC-13, 0.2 A at 110 V, operating rate <3600 cyc/h, load factor: 0.5 conforming to EN/IEC 60947-5-1 appendix C
    1000000 cycles, DC-13, 0.5 A at 24 V, operating rate <3600 cyc/h, load factor: 0.5 conforming to EN/IEC 60947-5-1 appendix C
    electrical reliabilityΛ < 10exp(-6) at 5 V and 1 mA in clean environment conforming to EN/IEC 60947-5-4
    Λ < 10exp(-8) at 17 V and 5 mA in clean environment conforming to EN/IEC 60947-5-4
    signalling typeSteady
    current consumption14 mA
    service life100000 h at rated voltage and 25 °C
    surge withstand1 kV conforming to IEC 61000-4-5
    supply voltage limits100…132 V AC
    device presentationComplete product
    Environment (see above)
    protective treatmentTH
    ambient air temperature for storage-40…70 °C
    ambient air temperature for operation-40…70 °C
    electrical shock protection classClass I conforming to IEC 60536
    IP degree of protectionIP66 conforming to IEC 60529
    IP67
    IP69
    IP69K
    NEMA degree of protectionNEMA 13
    NEMA 4X
    IK degree of protectionIK06 conforming to IEC 50102
    standardsJIS C8201-5-1
    EN/IEC 60947-1
    EN/IEC 60947-5-4
    EN/IEC 60947-5-5
    CSA C22.2 No 14
    UL 508
    EN/IEC 60947-5-1
    JIS C8201-1
    product certificationsLROS (Lloyds register of shipping)
    BV
    UL listed
    CSA
    DNV
    GL
    vibration resistance5 gn (f= 2…500 Hz) conforming to IEC 60068-2-6
    shock resistance30 gn (duration = 18 ms) for half sine wave acceleration conforming to IEC 60068-2-27
    50 gn (duration = 11 ms) for half sine wave acceleration conforming to IEC 60068-2-27
    resistance to fast transients2 kV conforming to IEC 61000-4-4
    resistance to electromagnetic fields10 V/m conforming to IEC 61000-4-3
    resistance to electrostatic discharge6 kV on contact (on metal parts) conforming to IEC 61000-4-2
    8 kV in free air (in insulating parts) conforming to IEC 61000-4-2
    electromagnetic emissionClass B conforming to IEC 55011
    Packing Units (see above)
    Unit Type of Package 1PCE
    Number of Units in Package 11
    Package 1 Weight96 g
    Package 1 Height3.5 cm
    Package 1 width5.4 cm
    Package 1 Length9.2 cm
    Offer Sustainability (see above)
    Sustainable offer statusGreen Premium product
    REACh RegulationREACh Declaration
    REACh free of SVHCYes
    EU RoHS Directive
    Pro-active compliance (Product out of EU RoHS legal scope)
    EU RoHS Declaration
    Mercury freeYes
    RoHS exemption informationYes
    China RoHS RegulationChina RoHS declaration
    Environmental DisclosureProduct Environmental Profile
    Circularity ProfileEnd of Life Information
    WEEEThe product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins
    California proposition 65WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov

    Contractual warranty (see above)
    Warranty12 months
