Schneider Blue complete pilot light (D)22 plain lens with integral LED 110...120V

Schneider Blue complete pilot light (D)22 plain lens with integral LED 110...120V

Terjual 0

0 (0 Rating)

Ulasan (0)

Rp 116.733,00
43.00 % Rp 204.795,00 116733 IDR

Rp 204.795,00

Atur Jumlah & Catatan

Stock Total: 6

Keranjang Beli Sekarang

Spesifikasi

Main (see above)
range of product	Harmony XB5
product or component type	Pilot light
device short name	XB5
bezel material	Dark grey plastic
fixing collar material	Plastic
head type	Standard
mounting diameter	22 mm
sale per indivisible quantity	1
shape of signaling unit head	Round
cap/operator or lens colour	Blue
operator additional information	With plain lens
light source	Protected LED
bulb base	Integral LED
light source colour	Blue
[Us] rated supply voltage	110...120 V AC at 50/60 Hz
device presentation	Complete product

Complementary (see above)
height	42 mm
width	30 mm
depth	54 mm
terminals description ISO n°1	(X1-X2)PL
net weight	0.038 kg
resistance to high pressure washer	7000000 Pa at 55 °C, distance : 0.1 m
connections - terminals	Screw clamp terminals, <= 2 x 1.5 mm² with cable end conforming to EN/IEC 60947-1 Screw clamp terminals, 1 x 0.22...2 x 2.5 mm² without cable end conforming to EN/IEC 60947-1
[Ui] rated insulation voltage	250 V (pollution degree 3) conforming to EN 60947-1
[Uimp] rated impulse withstand voltage	EN 60947-1 4 kV
signalling type	Steady
GCR BRIDGE	XB5AVCUST04
compatibility code	XB5
supply voltage limits	100…132 V AC
current consumption	14 mA
service life	100000 h at rated voltage and 25 °C
surge withstand	1 kV conforming to IEC 61000-4-5

Environment (see above)
protective treatment	TH
ambient air temperature for storage	-40…70 °C
ambient air temperature for operation	-40…70 °C
overvoltage category	Class II conforming to IEC 60536
IP degree of protection	IP66 conforming to IEC 60529 IP67 conforming to IEC 60529 IP69 conforming to IEC 60529 IP69K conforming to ISO 20653
NEMA degree of protection	NEMA 13 NEMA 4X
IK degree of protection	IK05 conforming to IEC 50102
product certifications	CSA UL listed
vibration resistance	5 gn (f= 12…500 Hz) conforming to IEC 60068-2-6
shock resistance	50 gn (duration = 18 ms) for half sine wave acceleration conforming to IEC 60068-2-27 30 gn (duration = 11 ms) for half sine wave acceleration conforming to IEC 60068-2-27
resistance to fast transients	2 kV conforming to IEC 61000-4-4
resistance to electromagnetic fields	10 V/m conforming to IEC 61000-4-3
electromagnetic compatibility	Electrostatic discharge - test level: 6 kV (on contact (on metal parts)) conforming to IEC 61000-4-2 Electrostatic discharge - test level: 8 kV (in free air (in insulating parts)) conforming to IEC 61000-4-2 Electromagnetic emission class B conforming to IEC 55011
resistance to electrostatic discharge	6 kV on contact (on metal parts) conforming to IEC 61000-4-2 8 kV in free air (in insulating parts) conforming to IEC 61000-4-2
electromagnetic emission	Class B conforming to IEC 55011

Packing Units (see above)
Unit Type of Package 1	PCE
Number of Units in Package 1	1
Package 1 Weight	36 g
Package 1 Height	5 cm
Package 1 width	8.4 cm
Package 1 Length	3.4 cm
Unit Type of Package 2	S02
Number of Units in Package 2	50
Package 2 Weight	2.125 kg
Package 2 Height	15 cm
Package 2 width	30 cm
Package 2 Length	40 cm

Offer Sustainability (see above)
Sustainable offer status	Green Premium product
REACh Regulation	REACh Declaration
REACh free of SVHC	Yes
EU RoHS Directive	Pro-active compliance (Product out of EU RoHS legal scope) EU RoHS Declaration
Mercury free	Yes
RoHS exemption information	Yes
China RoHS Regulation	China RoHS declaration
Environmental Disclosure	Product Environmental Profile
Circularity Profile	End of Life Information
WEEE	The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins
California proposition 65	WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov

Contractual warranty (see above)
Warranty	12 months

https://www.se.com/id/en/product/XB5AVG6
