  4. Schneider LIMIT SWITCH WITH ROLLER PLUNGER

Schneider LIMIT SWITCH WITH ROLLER PLUNGER

Rp 336,445.00 Rp 238,875.00 238875 IDR

Rp 336,445.00

Option not available

    This combination does not exist.

    Add to Cart

    Schneider LIMIT SWITCH WITH ROLLER PLUNGER
    Terjual 0
    0 (0 Rating)
    Ulasan (0)

    Rp 238,875.00
    29.00 % Rp 336,445.00 238875 IDR

    Rp 336,445.00

    Option not available

    Atur Jumlah & Catatan
    Stock Total: 13
    Keranjang Beli Sekarang
    Spesifikasi
    Main (see above)
    range of product
    OsiSense XC
    series name
    Basic
    product or component type
    Limit switch
    product specific application
    Light to medium duty
    device short name
    XCJ
    body type
    Fixed
    head type
    Plunger head
    material
    Plastic and metal
    fixing mode
    By the body
    movement of operating head
    Linear
    type of operator
    Spring return roller plunger stainless steel
    switch actuation
    On end
    type of approach
    Lateral approach, 1 direction
    electrical connection
    Screw-clamp terminals
    cable entry
    1 flexible rubber cable gland, cable outer diameter: 8.5…10.5 mm
    number of poles
    1
    contact operation
    Snap action
    positive opening
    Without
    maximum force for tripping
    4 N
    Complementary (see above)
    contacts insulation form
    C
    minimum release force
    0.98 N
    minimum actuation speed
    0.01 mm/s
    maximum actuation speed
    0.5 m/s
    maximum operating rate
    120 cyc/mn
    contact code designation
    A300, AC (Ue = 240 V), Ie = 10 A, Ithe = 10 A conforming to IEC 60947-5-1
    R300, DC (Ue = 220 V), Ie = 0.3 A conforming to IEC 60947-5-1
    maximum resistance across terminals
    25 MOhm
    [Uimp] rated impulse withstand voltage
    4 kV conforming to EN/IEC 60664
    electrical durability
    800000 cycles, AC, 10 A, 220 V
    mechanical durability
    10000000 cycles
    width
    22 mm
    height
    79 mm
    depth
    70 mm
    net weight
    0.093 kg
    terminals description ISO n°1
    (NO-NC-C)OF
    Environment (see above)
    shock resistance
    10 gn for 11 ms conforming to IEC 60068-2-27
    vibration resistance
    +/- 3 mm (f= 10…55 Hz) conforming to IEC 60068-2-6
    IP degree of protection
    IP40 conforming to IEC 60529
    electrical shock protection class
    Class II conforming to EN/IEC 60947-5-1
    ambient air temperature for operation
    -25…70 °C
    ambient air temperature for storage
    -40…70 °C
    marking
    CE
    CCC
    standards
    IEC 60947-5-1
    GB 14048.5
    Packing Units (see above)
    Unit Type of Package 1
    PCE
    Number of Units in Package 1
    1
    Package 1 Weight
    92.3 g
    Package 1 Height
    6.38 cm
    Package 1 width
    2.14 cm
    Package 1 Length
    7.5 cm
    Offer Sustainability (see above)
    REACh Regulation
    EU RoHS Directive
    Pro-active compliance (Product out of EU RoHS legal scope)
    EU RoHS Declaration
    Mercury free
    Yes
    RoHS exemption information
    Contractual warranty (see above)
    Warranty
    12 months
