Schneider Circuit breaker Easypact EZC400H - TMD - 320 A - 3 poles 3d
# of Pole : 3
Arus Nominal (In) : 320A
Schneider Circuit breaker Easypact EZC400H - TMD - 320 A - 3 poles 3d
Terjual 0
0 (0 Rating)
Ulasan (0)
Rp 3.375.654,00
49.00 %
Rp 6.618.930,00
Rp 6.618.930,00
Option not available
Spesifikasi
| range of product | EasyPact | |
|---|---|---|
| product or component type | Circuit breaker | |
| device short name | Easypact EZC400H | |
| circuit breaker name | Easypact EZC400H | |
| device application | Distribution | |
| poles description | 3P | |
| protected poles description | 3t | |
| network type | AC DC | |
| network frequency | 50/60 Hz | |
| [In] rated current | 400 A at 40 °C | |
| [Ui] rated insulation voltage | 690 V AC 50/60 Hz conforming to IEC 60947-2 | |
| [Uimp] rated impulse withstand voltage | 6 kV conforming to IEC 60947-2 | |
| [Ue] rated operational voltage | 250 V DC conforming to IEC 60947-2 440 V AC 50/60 Hz conforming to IEC 60947-2 | |
| breaking capacity code | H | |
| breaking capacity | 50 kA Icu at 380 V AC 50/60 Hz conforming to IEC 60947-2 50 kA Icu at 440 V AC 50/60 Hz conforming to IEC 60947-2 70 kA Icu at 220/230 V AC 50/60 Hz conforming to IEC 60947-2 50 kA Icu at 400/415 V AC 50/60 Hz conforming to IEC 60947-2 | |
| [Ics] rated service breaking capacity | 25 kA at 380 V AC 50/60 Hz conforming to IEC 60947-2 25 kA at 400/415 V AC 50/60 Hz conforming to IEC 60947-2 25 kA at 440 V AC 50/60 Hz conforming to IEC 60947-2 35 kA at 220/230 V AC 50/60 Hz conforming to IEC 60947-2 | |
| suitability for isolation | Yes conforming to IEC 60947-2 | |
| utilisation category | Category A | |
| trip unit name | TM-D | |
| trip unit technology | Thermal-magnetic | |
| trip unit rating | 320 A at 50 °C | |
| protection type | Overload protection Short-circuit protection | |
| pollution degree | 3 conforming to IEC 60947 |
| control type | Toggle | |
|---|---|---|
| mounting mode | Fixed | |
| mounting support | Backplate | |
| upside connection | Front | |
| downside connection | Front | |
| mechanical durability | 10000 cycles | |
| electrical durability | Category A: 3000 cycles 415 V AC 50/60 Hz conforming to IEC 60947-2 | |
| connection pitch | 45 mm | |
| local signalling | Positive contact indication | |
| contact position indicator | Yes | |
| magnetic tripping current | 4000 A | |
| neutral protection setting | Without protection | |
| long time pick-up adjustment type Ir | Fixed | |
| long time delay adjustment type | Fixed | |
| earth-leakage protection | Without | |
| height | 255 mm | |
| width | 185 mm | |
| depth | 140 mm | |
| net weight | 6.4 kg | |
| quantity per set | 1 piece | |
| colour | Black |
| standards | EN/IEC 60947-2 GB/T 14048.2 EN/IEC 60947-1 JIS C8201-2-2 | |
|---|---|---|
| IP degree of protection | IP20 conforming to IEC 60529 | |
| IK degree of protection | IK07 conforming to EN 50102 | |
| ambient air temperature for operation | -25…70 °C | |
| ambient air temperature for storage | -35…85 °C |
| Unit Type of Package 1 | PCE | |
|---|---|---|
| Number of Units in Package 1 | 1 | |
| Package 1 Weight | 5.231 kg | |
| Package 1 Height | 15 cm | |
| Package 1 width | 16 cm | |
| Package 1 Length | 29 cm |
| Sustainable offer status | Green Premium product | |
|---|---|---|
| REACh Regulation | ||
| EU RoHS Directive | Compliant EU RoHS Declaration | |
| Mercury free | Yes | |
| RoHS exemption information | ||
| China RoHS Regulation | China RoHS declaration Product out of China RoHS scope. Substance declaration for your information | |
| Environmental Disclosure | ||
| WEEE | The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins | |
| PVC free | Yes |
| Warranty | 12 months |
|---|
