  4. Schneider Motor circuit breaker, TeSys GV2, 3P, 25 A, magnetic, rotary handle, screw clamp terminals

Schneider Motor circuit breaker, TeSys GV2, 3P, 25 A, magnetic, rotary handle, screw clamp terminals

# of Pole : 3

Arus Pengenal (A) : 25A

Rp 1,597,190.00 Rp 894,426.00 894426 IDR

Rp 1,597,190.00

Option not available

  • # of Pole
  • Arus Pengenal (A)

This combination does not exist.

Add to Cart

Schneider Motor circuit breaker, TeSys GV2, 3P, 25 A, magnetic, rotary handle, screw clamp terminals
Terjual 0
0 (0 Rating)
Ulasan (0)

Rp 894,426.00
44.00 % Rp 1,597,190.00 894426 IDR

Rp 1,597,190.00

Option not available

Atur Jumlah & Catatan
Stock Total: 15

# of Pole : 3

Arus Pengenal (A) : 25A

Keranjang Beli Sekarang
Spesifikasi

[Deskripsi] Tesys GV2 motor circuit breaker memberikan isolasi manual, pengendalian motor manual dan perlindungan thermal dan sirkuit pendek dengan panjang standar 45mm. [Spesifikasi] 1. product name : TeSys GV2 2. device short name : GV2L 3. device application : Motor 4. poles description : 3P 5. network type : AC 6. utilisation category : -Category A conforming to IEC 60947-2 -AC-3 conforming to IEC 60947-4-1 7. network frequency : 50/60 Hz conforming to IEC 60947-2 8. breaking capacity : -100 kA Icu at 230/240 V AC 50/60 Hz conforming to IEC 60947-2 -4 kA Icu at 690 V AC 50/60 Hz conforming to IEC 60947-2 -10 kA Icu at 500 V AC 50/60 Hz conforming to IEC 60947-2 -20 kA Icu at 440 V AC 50/60 Hz conforming to IEC 60947-2 -50 kA Icu at 400/415 V AC 50/60 Hz conforming to IEC 60947-2 -50 kA Icu at 230/240 V AC 50/60 Hz conforming to IEC 60947-2 9. [Ics] rated service short-circuit breaking capacity -100 % at 690 V AC 50/60 Hz conforming to IEC 60947-2 -100 % at 230/240 V AC 50/60 Hz conforming to IEC 60947-2 -75 % at 440 V AC 50/60 Hz conforming to IEC 60947-2 -75 % at 500 V AC 50/60 Hz conforming to IEC 60947-2 -50 % at 400/415 V AC 50/60 Hz conforming to IEC 60947-2 10. trip unit technology : Magnetic 11. magnetic tripping current : 327 A 12. fixing mode : -Clipped on 35 mm symmetrical DIN rail -Panel: screwed (with 2 x M4 screws) 13. operating position : Any position 14. motor power kW : -9 kW at 400/415 V AC 50/60 Hz -11 kW at 400/415 V AC 50/60 Hz -11 kW at 500 V AC 50/60 Hz -15 kW at 500 V AC 50/60 Hz -18.5 kW at 690 V AC 50/60 Hz 15. control type : Rotary knob 16. [Ue] rated operational voltage : 690 V AC 50/60 Hz conforming to IEC 60947-2 17. [Ui] rated insulation voltage : 690 V AC 50/60 Hz conforming to IEC 60947-2 18. [Uimp] rated impulse withstand voltage : 6 kV conforming to IEC 60947-2 19. power dissipation per pole : 1.8 W 20. height : 89 mm 21. width : 45 mm 22. depth : 97 mm 23. net weight : 0.33 kg


Main (see above)
range
TeSys
product name
TeSys GV2
product or component type
Circuit breaker
device short name
GV2L
device application
Motor
poles description
3P
network type
AC
utilisation category
Category A conforming to IEC 60947-2
AC-3 conforming to IEC 60947-4-1
network frequency
50/60 Hz conforming to IEC 60947-2
breaking capacity
4 kA Icu at 690 V AC 50/60 Hz conforming to IEC 60947-2
10 kA Icu at 500 V AC 50/60 Hz conforming to IEC 60947-2
20 kA Icu at 440 V AC 50/60 Hz conforming to IEC 60947-2
50 kA Icu at 400/415 V AC 50/60 Hz conforming to IEC 60947-2
50 kA Icu at 230/240 V AC 50/60 Hz conforming to IEC 60947-2
[Ics] rated service short-circuit breaking capacity
100 % at 690 V AC 50/60 Hz conforming to IEC 60947-2
100 % at 230/240 V AC 50/60 Hz conforming to IEC 60947-2
75 % at 440 V AC 50/60 Hz conforming to IEC 60947-2
75 % at 500 V AC 50/60 Hz conforming to IEC 60947-2
50 % at 400/415 V AC 50/60 Hz conforming to IEC 60947-2
trip unit technology
Magnetic
magnetic tripping current
327 A
Complementary (see above)
fixing mode
35 mm symmetrical DIN rail: clipped
Panel: screwed (with 2 x M4 screws)
operating position
Any position
motor power kW
9 kW at 400/415 V AC 50/60 Hz
11 kW at 400/415 V AC 50/60 Hz
11 kW at 500 V AC 50/60 Hz
15 kW at 500 V AC 50/60 Hz
18.5 kW at 690 V AC 50/60 Hz
control type
Rotary knob
[Ue] rated operational voltage
690 V AC 50/60 Hz conforming to IEC 60947-2
[Ui] rated insulation voltage
690 V AC 50/60 Hz conforming to IEC 60947-2
[Uimp] rated impulse withstand voltage
IEC 60947-2 6 kV
power dissipation per pole
1.8 W
mechanical durability
100000 cycles
electrical durability
100000 cycles for AC-3 at 415 V
maximum operating rate
40 cyc/h
rated duty
Continuous conforming to IEC 60947-4-1
connections - terminals
Screw clamp terminals 2 cable(s) 1…6 mm² solid
Screw clamp terminals 2 cable(s) 1.5…6 mm² flexible without cable end
Screw clamp terminals 2 cable(s) 1…4 mm² flexible with cable end
tightening torque
1.7 N.m on screw clamp terminals
mechanical robustness
Shocks: 30 Gn conforming to IEC 60068-2-27
Vibrations: 5 Gn, 5...150 Hz conforming to IEC 60068-2-6
suitability for isolation
Yes conforming to IEC 60947-1
height
89 mm
width
45 mm
depth
97 mm
net weight
0.33 kg
Environment (see above)
standards
EN/IEC 60947-2
EN/IEC 60947-4-1
CSA C22.2 No 60947-4-1
UL 60947-4-1
product certifications
IECEE CB Scheme
UL
CSA
CCC
EAC
RINA
LROS (Lloyds register of shipping)
DNV-GL
BV
protective treatment
TH
IP degree of protection
IP20 conforming to IEC 60529
IK degree of protection
IK04
ambient air temperature for operation
-20…60 °C
ambient air temperature for storage
-40…80 °C
fire resistance
960 °C conforming to IEC 60695-2-1
operating altitude
0...2000 m
Packing Units (see above)
Unit Type of Package 1
PCE
Number of Units in Package 1
1
Package 1 Weight
336 g
Package 1 Height
10.5 cm
Package 1 width
9.4 cm
Package 1 Length
5 cm
Unit Type of Package 2
S02
Number of Units in Package 2
20
Package 2 Weight
7.07 kg
Package 2 Height
15 cm
Package 2 width
30 cm
Package 2 Length
40 cm
Unit Type of Package 3
P06
Number of Units in Package 3
320
Package 3 Weight
121.7 kg
Package 3 Height
80 cm
Package 3 width
80 cm
Package 3 Length
60 cm
Offer Sustainability (see above)
Sustainable offer status
Green Premium product
REACh Regulation
EU RoHS Directive
Mercury free
Yes
RoHS exemption information
China RoHS Regulation
China RoHS declaration
Product out of China RoHS scope. Substance declaration for your information
Environmental Disclosure
WEEE
The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins
California proposition 65
WARNING: This product can expose you to chemicals including: Antimony oxide & Antimony trioxide, which is known to the State of California to cause cancer. For more information go to www.P65Warnings.ca.gov
Contractual warranty (see above)
Warranty
12 months
