  4. Schneider Motor circuit breaker, TeSys GV3, 3P, 37-50 A, thermal magnetic, EverLink terminals

Schneider Motor circuit breaker, TeSys GV3, 3P, 37-50 A, thermal magnetic, EverLink terminals

# of Pole : 3

Arus Pengenal (A) : 50A

Rp 3,528,223.00 Rp 1,975,804.00 1975804 IDR

Rp 3,528,223.00

Option not available

  • # of Pole
  • Arus Pengenal (A)

This combination does not exist.

Add to Cart

Schneider Motor circuit breaker, TeSys GV3, 3P, 37-50 A, thermal magnetic, EverLink terminals
Terjual 0
0 (0 Rating)
Ulasan (0)

Rp 1,975,804.00
44.00 % Rp 3,528,223.00 1975804 IDR

Rp 3,528,223.00

Option not available

Atur Jumlah & Catatan
Stock Total: 30

# of Pole : 3

Arus Pengenal (A) : 50A

Keranjang Beli Sekarang
Spesifikasi

[Deskripsi] Pemutus sirkuit motor termal-magnetik dan magnetik hingga 80 A dan 45 kW. Pemutus sirkuit motor TeSys GV3 menyediakan isolasi, kontrol motor dan perlindungan arus berlebih termal dalam satuan lebar standar 55 mm. [Spesifikasi] 1. product name : TeSys GV3 2. device short name : GV3ME 3. device application : Motor 4. trip unit technology : Thermal-magnetic 5. poles description : 3P 6. network type : AC 7. utilisation category : -AC-3 conforming to IEC 60947-4-1 -Category A conforming to IEC 60947-2 8. network frequency : 50/60 Hz conforming to IEC 60947-4-1 9. fixing mode : -35 mm symmetrical DIN rail: clipped -Panel: screwed (with 2 x M4 screws) 10. operating position : Any position 11. motor power kW : -22 kW at 400/415 V AC 50/60 Hz -30 kW at 500 V AC 50/60 Hz -45 kW at 690 V AC 50/60 Hz 12. breaking capacity : -100 kA Icu at 230/240 V AC 50/60 Hz conforming to IEC 60947-2 -50 kA Icu at 440 V AC 50/60 Hz conforming to IEC 60947-2 -6 kA Icu at 690 V AC 50/60 Hz conforming to IEC 60947-2 -50 kA Icu at 400/415 V AC 50/60 Hz conforming to IEC 60947-2 -12 kA Icu at 500 V AC 50/60 Hz conforming to IEC 60947-2 13. [Ics] rated service short-circuit breaking capacity : -100 % at 690 V AC 50/60 Hz conforming to IEC 60947-2 -100 % at 500 V AC 50/60 Hz conforming to IEC 60947-2 -100 % at 230/240 V AC 50/60 Hz conforming to IEC 60947-2 -50 % at 400/415 V AC 50/60 Hz conforming to IEC 60947-2 -60 % at 440 V AC 50/60 Hz conforming to IEC 60947-2 14. control type : Rotary knob 15. [In] rated current : 50 A 16. thermal protection adjustment range : 37…50 A 17. magnetic tripping current : 700 A 18. [Ue] rated operational voltage : 690 V AC 50/60 Hz conforming to IEC 60947-2 19. [Ui] rated insulation voltage : 690 V AC 50/60 Hz conforming to IEC 60947-2 20. [Ith] conventional free air thermal current : 50 A conforming to IEC 60947-4-1 21. height : 132 mm 22. width : 55 mm 23. depth : 136 mm 24. net weight : 0.96 kg


Main (see above)
range
TeSys
product name
TeSys GV3
product or component type
Circuit breaker
device short name
GV3P
device application
Motor
trip unit technology
Thermal-magnetic
Complementary (see above)
poles description
3P
network type
AC
utilisation category
AC-3 conforming to IEC 60947-4-1
Category A conforming to IEC 60947-2
network frequency
50/60 Hz conforming to IEC 60947-4-1
fixing mode
35 mm symmetrical DIN rail: clipped
Panel: screwed (with 3 x M4 screws)
operating position
Any position
motor power kW
22 kW at 400/415 V AC 50/60 Hz
30 kW at 500 V AC 50/60 Hz
45 kW at 690 V AC 50/60 Hz
breaking capacity
100 kA Icu at 230/240 V AC 50/60 Hz conforming to IEC 60947-2
50 kA Icu at 440 V AC 50/60 Hz conforming to IEC 60947-2
6 kA Icu at 690 V AC 50/60 Hz conforming to IEC 60947-2
50 kA Icu at 400/415 V AC 50/60 Hz conforming to IEC 60947-2
12 kA Icu at 500 V AC 50/60 Hz conforming to IEC 60947-2
[Ics] rated service short-circuit breaking capacity
100 % at 230/240 V AC 50/60 Hz conforming to IEC 60947-2
100 % at 440 V AC 50/60 Hz conforming to IEC 60947-2
100 % at 400/415 V AC 50/60 Hz conforming to IEC 60947-2
50 % at 500 V AC 50/60 Hz conforming to IEC 60947-2
50 % at 690 V AC 50/60 Hz conforming to IEC 60947-2
control type
Rotary knob
[In] rated current
50 A
thermal protection adjustment range
37…50 A
magnetic tripping current
700 A
[Ue] rated operational voltage
690 V AC 50/60 Hz conforming to IEC 60947-2
[Ui] rated insulation voltage
690 V AC 50/60 Hz conforming to IEC 60947-2
[Ith] conventional free air thermal current
50 A conforming to IEC 60947-4-1
[Uimp] rated impulse withstand voltage
IEC 60947-2 6 kV
power dissipation per pole
8 W
mechanical durability
50000 cycles
electrical durability
50000 cycles for AC-3 at 440 V In
maximum operating rate
25 cyc/h
rated duty
Continuous conforming to IEC 60947-4-1
tightening torque
5 N.m on EverLink BTR screw connectors for cable 25 mm²
8 N.m on EverLink BTR screw connectors for cable 35 mm²
suitability for isolation
Yes conforming to IEC 60947-1
phase failure sensitivity
Yes conforming to IEC 60947-4-1
height
132 mm
width
55 mm
depth
136 mm
net weight
0.96 kg
Environment (see above)
standards
EN/IEC 60947-2
EN/IEC 60947-4-1
CSA C22.2 No 60947-4-1
UL 60947-4-1
product certifications
IECEE CB Scheme
UL
CSA
CCC
EAC
ATEX
BV
LROS (Lloyds register of shipping)
DNV-GL
ABS
protective treatment
TH
IP degree of protection
IP20 conforming to IEC 60529
IK degree of protection
IK09
ambient air temperature for operation
-20…60 °C
ambient air temperature for storage
-40…80 °C
fire resistance
960 °C conforming to IEC 60695-2-1
operating altitude
3000 m
Packing Units (see above)
Unit Type of Package 1
PCE
Number of Units in Package 1
1
Package 1 Weight
1.012 kg
Package 1 Height
6.455 cm
Package 1 width
14.519 cm
Package 1 Length
15.579 cm
Unit Type of Package 2
P06
Number of Units in Package 2
120
Package 2 Weight
133.96 kg
Package 2 Height
75 cm
Package 2 width
80 cm
Package 2 Length
60 cm
Offer Sustainability (see above)
Sustainable offer status
Green Premium product
REACh Regulation
EU RoHS Directive
Mercury free
Yes
RoHS exemption information
China RoHS Regulation
China RoHS declaration
Product out of China RoHS scope. Substance declaration for your information
Environmental Disclosure
WEEE
The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins
Contractual warranty (see above)
Warranty
12 months

Specifications for Schneider Motor circuit breaker, TeSys GV3, 3P, 37-50 A, thermal magnetic, EverLink terminals

# of Pole 3
Arus Pengenal (A) 50A
