  4. Schneider Motor circuit breaker, TeSys GV3, 3P, 62-73 A, thermal magnetic, EverLink terminals

Schneider Motor circuit breaker, TeSys GV3, 3P, 62-73 A, thermal magnetic, EverLink terminals

Rp 4,840,321.00 Rp 2,516,966.00 2516966 IDR

Rp 4,840,321.00

Option not available

    This combination does not exist.

    Add to Cart

    Schneider Motor circuit breaker, TeSys GV3, 3P, 62-73 A, thermal magnetic, EverLink terminals
    Terjual 0
    0 (0 Rating)
    Ulasan (0)

    Rp 2,516,966.00
    48.00 % Rp 4,840,321.00 2516966 IDR

    Rp 4,840,321.00

    Option not available

    Atur Jumlah & Catatan
    Stock Total: 10
    Keranjang Beli Sekarang
    Spesifikasi
    Main (see above)
    range
    TeSys
    product name
    TeSys GV3
    product or component type
    Circuit breaker
    device short name
    GV3P
    device application
    Motor
    trip unit technology
    Thermal-magnetic
    Complementary (see above)
    poles description
    3P
    network type
    AC
    utilisation category
    AC-3 conforming to IEC 60947-4-1
    Category A conforming to IEC 60947-2
    network frequency
    50/60 Hz
    fixing mode
    35 mm symmetrical DIN rail: clipped
    Panel: screwed (with 3 x M4 screws)
    operating position
    Any position
    motor power kW
    37 kW at 400/415 V AC 50/60 Hz
    55 kW at 690 V AC 50/60 Hz
    45 kW at 500 V AC 50/60 Hz
    breaking capacity
    50 kA Icu at 400/415 V AC 50/60 Hz
    50 kA Icu at 440 V AC 50/60 Hz
    12 kA Icu at 500 V AC 50/60 Hz
    6 kA Icu at 690 V AC 50/60 Hz
    65 kA Icu at 230/240 V AC 50/60 Hz
    [Ics] rated service short-circuit breaking capacity
    100 % at 230/240 V AC 50/60 Hz
    60 % at 400/415 V AC 50/60 Hz
    60 % at 440 V AC 50/60 Hz
    50 % at 500 V AC 50/60 Hz
    50 % at 690 V AC 50/60 Hz
    control type
    Rotary knob
    [In] rated current
    73 A
    thermal protection adjustment range
    62…73 A
    magnetic tripping current
    1120 A
    [Ue] rated operational voltage
    690 V AC 50/60 Hz
    [Ui] rated insulation voltage
    690 V AC 50/60 Hz conforming to IEC 60947-2
    [Uimp] rated impulse withstand voltage
    IEC 60947-2 6 kV
    power dissipation per pole
    8 W
    mechanical durability
    50000 cycles
    electrical durability
    20000 cycles for AC-3 at 415 V In
    maximum operating rate
    25 cyc/h
    rated duty
    Continuous conforming to IEC 60947-4-1
    tightening torque
    5 N.m on EverLink BTR screw connectors for cable 25 mm²
    8 N.m on EverLink BTR screw connectors for cable 35 mm²
    mechanical robustness
    Shocks: 30 Gn for 11 ms opened conforming to IEC 60068-2-27
    Vibrations: 4 Gn, 5...300 Hz conforming to IEC 60068-2-6
    Shocks: 5 Gn for 11 ms closed conforming to IEC 60068-2-27
    suitability for isolation
    Yes conforming to IEC 60947-1
    phase failure sensitivity
    Yes conforming to IEC 60947-4-1
    height
    132 mm
    width
    55 mm
    depth
    136 mm
    net weight
    0.96 kg
    colour
    Grey (SE GREY 6)
    Green (SE GREEN 2)
    Environment (see above)
    standards
    EN/IEC 60947-2
    EN/IEC 60947-4-1
    CSA C22.2 No 60947-4-1
    UL 60947-4-1
    product certifications
    IECEE CB Scheme
    UL
    CSA
    CCC
    EAC
    ATEX
    BV
    LROS (Lloyds register of shipping)
    DNV-GL
    ABS
    protective treatment
    TC
    IP degree of protection
    IP20 conforming to IEC 60529
    IK degree of protection
    IK09
    ambient air temperature for operation
    -20…60 °C
    ambient air temperature for storage
    -40…80 °C
    fire resistance
    960 °C conforming to IEC 60695-2-1
    operating altitude
    0...3000 m
    Packing Units (see above)
    Unit Type of Package 1
    PCE
    Number of Units in Package 1
    1
    Package 1 Weight
    1.011 kg
    Package 1 Height
    6.5 cm
    Package 1 width
    14.6 cm
    Package 1 Length
    16 cm
    Unit Type of Package 2
    P06
    Number of Units in Package 2
    120
    Package 2 Weight
    134.92 kg
    Package 2 Height
    75 cm
    Package 2 width
    60 cm
    Package 2 Length
    80 cm
    Offer Sustainability (see above)
    Sustainable offer status
    Green Premium product
    REACh Regulation
    EU RoHS Directive
    Mercury free
    Yes
    RoHS exemption information
    China RoHS Regulation
    China RoHS declaration
    Product out of China RoHS scope. Substance declaration for your information
    Environmental Disclosure
    WEEE
    The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins
    Contractual warranty (see above)
    Warranty
    12 months
