  2. Contactor
  3. TVS
  4. Schneider EasyPact TVS - auxiliary contact block - 1 NO + 1 NC - screw-clamps terminals

Schneider EasyPact TVS - auxiliary contact block - 1 NO + 1 NC - screw-clamps terminals

Rp 88,578.00 Rp 45,174.00 45174 IDR

Rp 88,578.00

Option not available

    This combination does not exist.

    Add to Cart

    Schneider EasyPact TVS - auxiliary contact block - 1 NO + 1 NC - screw-clamps terminals
    Terjual 0
    0 (0 Rating)
    Ulasan (0)

    Rp 45,174.00
    49.00 % Rp 88,578.00 45174 IDR

    Rp 88,578.00

    Option not available

    Atur Jumlah & Catatan
    Stock Total: 130
    Keranjang Beli Sekarang
    Spesifikasi

    [Deskripsi] 1. product or component type : Auxiliary contact block 2. device application : Signalling 3. product or component type : Auxiliary contact block 4. device application : Signalling 5. range compatibility : EasyPact TVS LC1E 6. mounting location : Front 7. auxiliary contacts operation : Instantaneous 8. pole contact composition : 1 NO + 1 NC 9. [Ui] rated insulation voltage : 690 V - for control circuit conforming to IEC 60947-5-1 10. [Ue] rated operational voltage : <= 690 V 11. [Ith] conventional free air thermal current : 8 A (at 60 °C) 12. Irms rated making capacity : 140 A AC conforming to IEC 60947-5-1 13. [Icw] rated short-time withstand current : -100 A - 1 s -120 A - 500 ms -140 A - 100 ms 14. protection type : GG fuse 10 A 15. mechanical durability : 10 Mcycles 16. minimum switching current : 5 mA 17. minimum switching voltage : 17 V 18. non-overlap time : -1.5 ms on energisation no overlap between NC and NO contact -1.5 ms on de-energisation no overlap between NC and NO contact 19. insulation resistance : > 10 MOhm 20. connections - terminals : -Control circuit: screw clamp terminals 1 1 mm² - external diameter: 6 mm - cable stiffness: solid or flexible with cable end -Control circuit: screw clamp terminals 1 1 mm² - external diameter: 6 mm - cable stiffness: solid or flexible without cable end -Control circuit: screw clamp terminals 2 2.5 mm² - external diameter: 6 mm - cable stiffness: solid or flexible with cable end -Control circuit: screw clamp terminals 2 2.5 mm² - external diameter: 6 mm - cable stiffness: solid or flexible without cable end 21. net weight : 0.035 kg 22. colour : Grey (RAL 7011)


    Main (see above)
    range
    EasyPact
    device short name
    LAEN
    product or component type
    Auxiliary contact block
    device application
    Signalling
    colour
    Grey (RAL 7011)
    Complementary (see above)
    range compatibility
    EasyPact TVS LC1E
    mounting location
    Front
    auxiliary contacts operation
    Instantaneous
    pole contact composition
    1 NO + 1 NC
    [Ui] rated insulation voltage
    690 V - for control circuit conforming to IEC 60947-5-1
    [Ue] rated operational voltage
    <= 690 V
    [Ith] conventional free air thermal current
    8 A (at 60 °C)
    Irms rated making capacity
    140 A AC conforming to IEC 60947-5-1
    [Icw] rated short-time withstand current
    100 A - 1 s
    120 A - 500 ms
    140 A - 100 ms
    protection type
    GG fuse 10 A
    mechanical durability
    10 Mcycles
    minimum switching current
    5 mA
    minimum switching voltage
    17 V
    non-overlap time
    1.5 ms on energisation no overlap between NC and NO contact
    1.5 ms on de-energisation no overlap between NC and NO contact
    insulation resistance
    > 10 MOhm
    connections - terminals
    Control circuit: screw clamp terminals 1 1 mm² - external diameter: 6 mm - cable stiffness: solid or flexible with cable end
    Control circuit: screw clamp terminals 1 1 mm² - external diameter: 6 mm - cable stiffness: solid or flexible without cable end
    Control circuit: screw clamp terminals 2 2.5 mm² - external diameter: 6 mm - cable stiffness: solid or flexible with cable end
    Control circuit: screw clamp terminals 2 2.5 mm² - external diameter: 6 mm - cable stiffness: solid or flexible without cable end
    net weight
    0.035 kg
    Environment (see above)
    environmental characteristic
    Standard environment
    standards
    IEC 60947-5-1
    product certifications
    GOST
    IP degree of protection
    IP20 conforming to IEC 60529
    protective treatment
    TH conforming to IEC 60068
    ambient air temperature for operation
    -5…55 °C
    ambient air temperature for storage
    -60…80 °C
    operating altitude
    3000 m without derating
    Packing Units (see above)
    Unit Type of Package 1
    PCE
    Number of Units in Package 1
    1
    Package 1 Weight
    34 g
    Package 1 Height
    2.4 cm
    Package 1 width
    4.2 cm
    Package 1 Length
    5 cm
    Unit Type of Package 2
    S02
    Number of Units in Package 2
    100
    Package 2 Weight
    3.751 kg
    Package 2 Height
    15 cm
    Package 2 width
    30 cm
    Package 2 Length
    40 cm
    Offer Sustainability (see above)
    REACh Regulation
    REACh free of SVHC
    Yes
    EU RoHS Directive
    Toxic heavy metal free
    Yes
    Mercury free
    Yes
    RoHS exemption information
    China RoHS Regulation
    China RoHS declaration
     Pro-active China RoHS declaration (out of China RoHS legal scope)
    WEEE
    The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins
    Contractual warranty (see above)
    Warranty
    12 months
