Schneider EasyPact TVS - time delay - on delay - 1 NO + 1 NC

Rp 1,144,443.00 Rp 640,888.00 640888 IDR

Rp 1,144,443.00

Option not available

    This combination does not exist.

    Add to Cart

    Schneider EasyPact TVS - time delay - on delay - 1 NO + 1 NC
    Terjual 0
    0 (0 Rating)
    Ulasan (0)

    Rp 640,888.00
    44.00 % Rp 1,144,443.00 640888 IDR

    Rp 1,144,443.00

    Option not available

    Atur Jumlah & Catatan
    Stock Total: 42
    Keranjang Beli Sekarang
    Spesifikasi
    Main (see above)
    range
    EasyPact
    device short name
    LAET
    product or component type
    Time delay auxiliary
    device application
    Signalling
    colour
    Grey (RAL 7011)
    Complementary (see above)
    range compatibility
    EasyPact TVS LC1E
    mounting location
    Front
    auxiliary contacts operation
    On-delay contact
    pole contact composition
    1 NO + 1 NC
    [Ui] rated insulation voltage
    690 V - for control circuit conforming to IEC 60947-5-1
    [Ue] rated operational voltage
    <= 690 V
    [Ith] conventional free air thermal current
    8 A (at 60 °C)
    Irms rated making capacity
    140 A AC conforming to IEC 60947-5-1
    [Icw] rated short-time withstand current
    100 A - 1 s
    120 A - 500 ms
    140 A - 100 ms
    protection type
    GG fuse 10 A
    mechanical durability
    10 Mcycles
    minimum switching current
    5 mA
    minimum switching voltage
    17 V
    non-overlap time
    1.5 ms on energisation no overlap between NC and NO contact
    1.5 ms on de-energisation no overlap between NC and NO contact
    time delay range
    1...30 s
    insulation resistance
    > 10 MOhm
    connections - terminals
    Control circuit: screw clamp terminals 1 1 mm² - external diameter: 6 mm - cable stiffness: solid or flexible with cable end
    Control circuit: screw clamp terminals 1 1 mm² - external diameter: 6 mm - cable stiffness: solid or flexible without cable end
    Control circuit: screw clamp terminals 2 2.5 mm² - external diameter: 6 mm - cable stiffness: solid or flexible with cable end
    Control circuit: screw clamp terminals 2 2.5 mm² - external diameter: 6 mm - cable stiffness: solid or flexible without cable end
    net weight
    0.06 kg
    Environment (see above)
    environmental characteristic
    Standard environment
    standards
    IEC 60947-5-1
    product certifications
    GOST
    IP degree of protection
    IP20 conforming to IEC 60529
    protective treatment
    TH conforming to IEC 60068
    ambient air temperature for operation
    -5…55 °C
    ambient air temperature for storage
    -60…80 °C
    operating altitude
    3000 m without derating
    Packing Units (see above)
    Unit Type of Package 1
    PCE
    Number of Units in Package 1
    1
    Package 1 Weight
    82 g
    Package 1 Height
    4.8 cm
    Package 1 width
    5.2 cm
    Package 1 Length
    6.5 cm
    Unit Type of Package 2
    BB1
    Number of Units in Package 2
    10
    Package 2 Weight
    835 g
    Package 2 Height
    5.2 cm
    Package 2 width
    13.5 cm
    Package 2 Length
    24 cm
    Unit Type of Package 3
    S03
    Number of Units in Package 3
    140
    Package 3 Weight
    12.403 kg
    Package 3 Height
    30 cm
    Package 3 width
    30 cm
    Package 3 Length
    40 cm
    Offer Sustainability (see above)
    Sustainable offer status
    Green Premium product
    REACh Regulation
    EU RoHS Directive
    Mercury free
    Yes
    RoHS exemption information
    China RoHS Regulation
    China RoHS declaration
    Product out of China RoHS scope. Substance declaration for your information
    Environmental Disclosure
    WEEE
    The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins
    Contractual warranty (see above)
    Warranty
    12 months
