Schneider TeSys LC1D.K capacitor duty contactor - 3P - 33.3 kVAR - 415 V - 220 V AC coil
# of Pole : 3
Coil AC : 220V (M7)
Schneider TeSys LC1D.K capacitor duty contactor - 3P - 33.3 kVAR - 415 V - 220 V AC coil
Terjual 0
0 (0 Rating)
Ulasan (0)
Rp 2.666.664,00
44.00 %
Rp 4.761.900,00
Rp 4.761.900,00
Option not available
Spesifikasi
[Deskripsi] 1. poles description : 3P 2. power pole contact composition : 3 NO 3. device location in system : -Line interruption -Inside delta interruption 4. [Ue] rated operational voltage : Power circuit: <= 690 V AC 50/60 Hz 5. reactive power rating : -17 kvar at 230 V AC 50/60 Hz 60 °C -30 kvar at 400…415 V AC 50/60 Hz 60 °C -32 kvar at 440 V AC 50/60 Hz 60 °C -50 kvar at 660…690 V AC 50/60 Hz 60 °C 6. control circuit type : AC at 50/60 Hz 7. [Uc] control circuit voltage : 220 V AC 50/60 Hz 8. auxiliary contact composition : -1 NO + 2 NC for signalling circuit -3 NO early make for power circuit 9. height : 166 mm 10. width : 55 mm 11. depth : 156 mm 12. net weight : 1.3 kg
| range | TeSys | |
|---|---|---|
| product name | TeSys LC1D.K | |
| product or component type | Capacitor duty contactor | |
| device short name | LC1DPK | |
| device application | Control | |
| contactor application | Power factor correction | |
| utilisation category | AC-6b | |
| poles description | 3P | |
| power pole contact composition | 3 NO | |
| device location in system | Inside delta interruption Line interruption | |
| [Ue] rated operational voltage | Power circuit: 690 V AC 50/60 Hz | |
| reactive power rating | 17 kvar at 230 V AC 50 Hz 60 °C 30 kvar at 400 V AC 50 Hz 60 °C 32 kvar at 440 V AC 50 Hz 60 °C 50 kvar at 690 V AC 50 Hz 60 °C 16.5 kvar at 230 V AC 60 Hz 60 °C 33.3 kvar at 460 V AC 60 Hz 60 °C 40 kvar at 575 V AC 60 Hz 60 °C | |
| control circuit type | AC at 50/60 Hz | |
| [Uc] control circuit voltage | 220 V AC 50/60 Hz | |
| auxiliary contact composition | 1 NO + 2 NC instantaneous | |
| electrical durability | 300000 cycles at Ue 400 V 200000 cycles at Ue 690 V | |
| mounting support | DIN rail Plate | |
| standards | EN/IEC 60947-1 EN/IEC 60947-4-1 UL 60947-4-1 CSA C22.2 No 60947-4-1 | |
| product certifications | IECEE CB Scheme UL CSA | |
| connections - terminals | Control circuit: screw clamp terminals 1 1…4 mm² - cable stiffness: solid Control circuit: screw clamp terminals 2 1…4 mm² - cable stiffness: solid Control circuit: screw clamp terminals 1 1…4 mm² - cable stiffness: flexible without cable end Control circuit: screw clamp terminals 2 1…4 mm² - cable stiffness: flexible without cable end Control circuit: screw clamp terminals 1 1…4 mm² - cable stiffness: flexible with cable end Control circuit: screw clamp terminals 2 1…2.5 mm² - cable stiffness: flexible with cable end Power circuit: EverLink BTR screw connectors 1 1…35 mm² - cable stiffness: solid Power circuit: EverLink BTR screw connectors 2 1…25 mm² - cable stiffness: solid Power circuit: EverLink BTR screw connectors 1 1…35 mm² - cable stiffness: flexible with or without cable end Power circuit: EverLink BTR screw connectors 2 1…25 mm² - cable stiffness: flexible with or without cable end | |
| tightening torque | Control circuit: 1.7 N.m - on screw clamp terminals Power circuit: 5 N.m - on EverLink BTR screw connectors - cable 1…25 mm² Power circuit: 8 N.m - on EverLink BTR screw connectors - cable 35 mm² | |
| maximum operating rate | 240 cyc/h |
| auxiliary contacts type | type mechanically linked 1 NO + 2 NC conforming to IEC 60947-5-1 |
|---|
| IP degree of protection | IP20 front face conforming to IEC 60529 | |
|---|---|---|
| ambient air temperature for operation | -5…60 °C | |
| ambient air temperature for storage | -60…80 °C | |
| operating altitude | 0...3000 m | |
| height | 166 mm | |
| width | 55 mm | |
| depth | 156 mm | |
| net weight | 1.3 kg |
| Unit Type of Package 1 | PCE | |
|---|---|---|
| Number of Units in Package 1 | 1 | |
| Package 1 Weight | 1.108 kg | |
| Package 1 Height | 7 cm | |
| Package 1 width | 20 cm | |
| Package 1 Length | 23 cm | |
| Unit Type of Package 2 | S03 | |
| Number of Units in Package 2 | 6 | |
| Package 2 Weight | 7.173 kg | |
| Package 2 Height | 30 cm | |
| Package 2 width | 30 cm | |
| Package 2 Length | 40 cm | |
| Unit Type of Package 3 | P06 | |
| Number of Units in Package 3 | 48 | |
| Package 3 Weight | 67.388 kg | |
| Package 3 Height | 80 cm | |
| Package 3 width | 80 cm | |
| Package 3 Length | 60 cm |
| REACh Regulation | ||
|---|---|---|
| REACh free of SVHC | Yes | |
| EU RoHS Directive | Compliant EU RoHS Declaration | |
| Toxic heavy metal free | Yes | |
| Mercury free | Yes | |
| RoHS exemption information | ||
| China RoHS Regulation | ||
| WEEE | The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins | |
| California proposition 65 | WARNING: This product can expose you to chemicals including: Antimony oxide & Antimony trioxide, which is known to the State of California to cause cancer. For more information go to www.P65Warnings.ca.gov |
| Warranty | 12 months |
|---|
Specifications for Schneider TeSys LC1D.K capacitor duty contactor - 3P - 33.3 kVAR - 415 V - 220 V AC coil
| General Information | |
|---|---|
| # of Pole | 3 |
| Uncategorized | |
| Coil AC | 220V (M7) |
