[Deskripsi] 1. product name : TeSys LE 2. device short name : LE1M 3. product or component type : Enclosed DOL starter 4. device application : Standard 5. utilisation category : AC-3 6. device composition : -Contactor -Earth terminal -Neutral terminal -Thermal overload relay 7. thermal protection adjustment range : 3.7…5.5 A 8. motor power kW : -0.75 kW at 240 V AC 50/60 Hz -2.2 kW at 415 V AC 50/60 Hz -1.1 kW at 220/230 V AC 50/60 Hz -2.2 kW at 380/400 V AC 50/60 Hz 9. [Uc] control circuit voltage : 380 V AC 50/60 Hz 10. control type : -Push-button start green I -Push-button stop/reset red O 11. local signalling : Operating: LED (yellow) 12. cable entry number : -2 ISO20 top -2 ISO25 top -2 Pg 13 top -2 Pg 21 top -2 ISO20 bottom -2 ISO25 bottom -2 Pg 13 bottom -2 Pg 21 bottom -2 Pg 16 top -2 Pg 16 bottom 13. width : 78 mm 14. height : 160 mm 15. depth : 108 mm 16. net weight : 0.6 kg
| range | TeSys | |
|---|---|---|
| product name | TeSys LE | |
| device short name | LE1M | |
| product or component type | Enclosed DOL starter | |
| device application | Standard | |
| utilisation category | AC-3 | |
| device composition | Contactor Earth terminal Neutral terminal Thermal overload relay | |
| thermal protection adjustment range | 3.7…5.5 A | |
| motor power kW | 0.75 kW at 240 V AC 50/60 Hz 2.2 kW at 415 V AC 50/60 Hz 1.1 kW at 220/230 V AC 50/60 Hz 2.2 kW at 380/400 V AC 50/60 Hz | |
| [Uc] control circuit voltage | 380 V AC 50/60 Hz | |
| control type | Push-button start green I Push-button stop/reset red O |
| local signalling | Operating: LED (yellow) | |
|---|---|---|
| cable entry number | 2 ISO20 top 2 ISO25 top 2 Pg 13 top 2 Pg 21 top 2 ISO20 bottom 2 ISO25 bottom 2 Pg 13 bottom 2 Pg 21 bottom 2 Pg 16 top 2 Pg 16 bottom | |
| width | 78 mm | |
| height | 160 mm | |
| depth | 108 mm | |
| net weight | 0.6 kg |
| material | ABS (acrylonitrile butadiene-styrene) | |
|---|---|---|
| IP degree of protection | IP65 conforming to IEC 60529 | |
| standards | IEC 60947-4-1 | |
| ambient air temperature for operation | -5…40 °C | |
| environmental characteristic | Standard environment |
| Unit Type of Package 1 | PCE | |
|---|---|---|
| Number of Units in Package 1 | 1 | |
| Package 1 Weight | 572.9 g | |
| Package 1 Height | 8.2 cm | |
| Package 1 width | 11.6 cm | |
| Package 1 Length | 16.6 cm |
| REACh Regulation | ||
|---|---|---|
| REACh free of SVHC | Yes | |
| EU RoHS Directive | Compliant EU RoHS Declaration | |
| Toxic heavy metal free | Yes | |
| Mercury free | Yes | |
| RoHS exemption information | ||
| China RoHS Regulation | ||
| WEEE | The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins |
| Warranty | 12 months |
|---|
Specifications for Schneider TeSys LE - enclosed DOL starter - 3.7...5.5 A - 380 V AC coil
| P (kW) | 2.2 |
