Schneider Circuit breaker EasyPact CVS100F, 36 kA at 415 VAC, 63 A rating thermal magnetic TM-D trip unit, 4P 3d
# of Pole : 4
Arus Nominal (In) : 63A
Icu (kA) : 36
Schneider Circuit breaker EasyPact CVS100F, 36 kA at 415 VAC, 63 A rating thermal magnetic TM-D trip unit, 4P 3d
Terjual 0
0 (0 Rating)
Ulasan (0)
Rp 1.343.921,00
49.00 %
Rp 2.635.140,00
Rp 2.635.140,00
Option not available
Spesifikasi
| range of product | Easypact CVS100...250 | |
|---|---|---|
| product or component type | Circuit breaker | |
| device short name | CVS100F | |
| device application | Distribution | |
| poles description | 4P | |
| protected poles description | 4d | |
| neutral position | Left | |
| Earth leakage protection (Vigi add on) | Without | |
| [In] rated current | 100 A at 40 °C | |
| breaking capacity code | F | |
| network type | AC | |
| [Icu] Breaking capacity | 36 kA Icu at 440 V AC 50/60 Hz conforming to IEC 60947-2 36 kA Icu at 380/415 V AC 50/60 Hz conforming to IEC 60947-2 70 kA Icu at 220/240 V AC 50/60 Hz conforming to IEC 60947-2 | |
| utilisation category | Category A | |
| trip unit name | TM-D | |
| trip unit technology | Thermal-magnetic | |
| trip unit rating | 63 A at 40 °C | |
| protection type | Short-circuit protection (magnetic) Overload protection (thermal) |
| network frequency | 50/60 Hz | |
|---|---|---|
| control type | Toggle | |
| mounting mode | Fixed | |
| mounting support | Backplate | |
| upside connection | Front | |
| downside connection | Front | |
| connections - terminals | Screw connection | |
| [Uimp] rated impulse withstand voltage | 8 kV conforming to EN/IEC 60947-2 | |
| thermal protection adjustment range | 44.1…63 A | |
| [Ics] rated service breaking capacity | 18 kA at 440 V AC 50/60 Hz conforming to IEC 60947-2 36 kA at 380/415 V AC 50/60 Hz conforming to IEC 60947-2 70 kA at 220/240 V AC 50/60 Hz conforming to IEC 60947-2 | |
| mechanical durability | 30000 cycles | |
| electrical durability | 12000 cycles 415 V In conforming to IEC 60947-2 | |
| connection pitch | 35 mm | |
| contact position indicator | Yes | |
| neutral protection setting | 1 x Ir (4d) | |
| long time pick-up adjustment type Ir | Adjustable | |
| long time pick-up adjustment range | 0.7...1 x In | |
| long time delay adjustment type | Fixed | |
| instantaneous pick-up adjustment type Ii | Fixed | |
| instantaneous pick-up adjustment range | 500 A | |
| height | 161 mm | |
| width | 140 mm | |
| depth | 86 mm | |
| net weight | 2.2 kg |
| electrical shock protection class | Class II | |
|---|---|---|
| standards | IEC 60947-2 EN 60947-2 | |
| product certifications | GOST IEC | |
| IP degree of protection | IP40 | |
| pollution degree | 3 conforming to IEC 60664-1 | |
| ambient air temperature for operation | -25…70 °C | |
| ambient air temperature for storage | -50…85 °C |
| Unit Type of Package 1 | PCE | |
|---|---|---|
| Number of Units in Package 1 | 1 | |
| Package 1 Weight | 2.17 kg | |
| Package 1 Height | 13.5 cm | |
| Package 1 width | 14.5 cm | |
| Package 1 Length | 19 cm |
| Sustainable offer status | Green Premium product | |
|---|---|---|
| REACh Regulation | ||
| EU RoHS Directive | Compliant EU RoHS Declaration | |
| Mercury free | Yes | |
| RoHS exemption information | ||
| China RoHS Regulation | China RoHS declaration Product out of China RoHS scope. Substance declaration for your information | |
| Environmental Disclosure | ||
| Circularity Profile | ||
| WEEE | The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins |
| Warranty | 12 months |
|---|
Specifications for Schneider Circuit breaker EasyPact CVS100F, 36 kA at 415 VAC, 63 A rating thermal magnetic TM-D trip unit, 4P 3d
| # of Pole | 4 |
| Arus Nominal (In) | 63A |
| Icu (kA) | 36 |
HOT PROMO
| range of product | Easypact CVS100...250 | |
|---|---|---|
| product or component type | Circuit breaker | |
| device short name | CVS100F | |
| device application | Distribution | |
| poles description | 4P | |
| protected poles description | 4d | |
| neutral position | Left | |
| Earth leakage protection (Vigi add on) | Without | |
| [In] rated current | 100 A at 40 °C | |
| breaking capacity code | F | |
| network type | AC | |
| [Icu] Breaking capacity | 36 kA Icu at 440 V AC 50/60 Hz conforming to IEC 60947-2 36 kA Icu at 380/415 V AC 50/60 Hz conforming to IEC 60947-2 70 kA Icu at 220/240 V AC 50/60 Hz conforming to IEC 60947-2 | |
| utilisation category | Category A | |
| trip unit name | TM-D | |
| trip unit technology | Thermal-magnetic | |
| trip unit rating | 63 A at 40 °C | |
| protection type | Short-circuit protection (magnetic) Overload protection (thermal) |
| network frequency | 50/60 Hz | |
|---|---|---|
| control type | Toggle | |
| mounting mode | Fixed | |
| mounting support | Backplate | |
| upside connection | Front | |
| downside connection | Front | |
| connections - terminals | Screw connection | |
| [Uimp] rated impulse withstand voltage | 8 kV conforming to EN/IEC 60947-2 | |
| thermal protection adjustment range | 44.1…63 A | |
| [Ics] rated service breaking capacity | 18 kA at 440 V AC 50/60 Hz conforming to IEC 60947-2 36 kA at 380/415 V AC 50/60 Hz conforming to IEC 60947-2 70 kA at 220/240 V AC 50/60 Hz conforming to IEC 60947-2 | |
| mechanical durability | 30000 cycles | |
| electrical durability | 12000 cycles 415 V In conforming to IEC 60947-2 | |
| connection pitch | 35 mm | |
| contact position indicator | Yes | |
| neutral protection setting | 1 x Ir (4d) | |
| long time pick-up adjustment type Ir | Adjustable | |
| long time pick-up adjustment range | 0.7...1 x In | |
| long time delay adjustment type | Fixed | |
| instantaneous pick-up adjustment type Ii | Fixed | |
| instantaneous pick-up adjustment range | 500 A | |
| height | 161 mm | |
| width | 140 mm | |
| depth | 86 mm | |
| net weight | 2.2 kg |
| electrical shock protection class | Class II | |
|---|---|---|
| standards | IEC 60947-2 EN 60947-2 | |
| product certifications | GOST IEC | |
| IP degree of protection | IP40 | |
| pollution degree | 3 conforming to IEC 60664-1 | |
| ambient air temperature for operation | -25…70 °C | |
| ambient air temperature for storage | -50…85 °C |
| Unit Type of Package 1 | PCE | |
|---|---|---|
| Number of Units in Package 1 | 1 | |
| Package 1 Weight | 2.17 kg | |
| Package 1 Height | 13.5 cm | |
| Package 1 width | 14.5 cm | |
| Package 1 Length | 19 cm |
| Sustainable offer status | Green Premium product | |
|---|---|---|
| REACh Regulation | ||
| EU RoHS Directive | Compliant EU RoHS Declaration | |
| Mercury free | Yes | |
| RoHS exemption information | ||
| China RoHS Regulation | China RoHS declaration Product out of China RoHS scope. Substance declaration for your information | |
| Environmental Disclosure | ||
| Circularity Profile | ||
| WEEE | The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins |
| Warranty | 12 months |
|---|
