  4. Schneider TeSys F - contactor coil - LX1FJ - 220...230 V AC 40...400 Hz

Schneider TeSys F - contactor coil - LX1FJ - 220...230 V AC 40...400 Hz

Rp 6,617,420.00 Rp 3,970,451.00 3970451 IDR

Rp 6,617,420.00

Option not available

    This combination does not exist.

    Add to Cart

    Schneider TeSys F - contactor coil - LX1FJ - 220...230 V AC 40...400 Hz
    Terjual 0
    0 (0 Rating)
    Ulasan (0)

    Rp 3,970,451.00
    40.00 % Rp 6,617,420.00 3970451 IDR

    Rp 6,617,420.00

    Option not available

    Atur Jumlah & Catatan
    Stock Total: 2
    Keranjang Beli Sekarang
    Spesifikasi

    [Deskripsi] TeSys F adalah rangkaian kontaktor arus tinggi dari 115 A hingga 1000 A yang dirancang untuk aplikasi AC-3 dan dari 200 A hingga 2600 A untuk aplikasi AC-1. [Spesifikasi] 1. circuit type : AC at 40...400 Hz 2. [Uc] control circuit voltage : 220...230 V AC 40...400 Hz 3. average resistance : -37 Ohm inrush at 20 °C -1030 Ohm holding at 20 °C 4. operating time : -100...170 ms opening -40...75 ms closing 5. mechanical durability : 10 Mcycles 6. maximum operating rate : 2400 cyc/h 55 °C 7. coil technology : Without built-in suppressor module 8. control circuit voltage limits : -Drop-out: 0.35...0.55 Uc 50/60 Hz (at 55 °C) -Operational: 0.85...1.1 Uc 50/60 Hz (at 55 °C) 9. inrush power in VA : 1075 VA 40...400 Hz cos phi 0.9 (at 20 °C) 10. hold-in power consumption in VA : 15 VA 40...400 Hz cos phi 0.3 (at 20 °C) 11. heat dissipation : 14 W at 40...400 Hz 12. ambient air temperature for operation : -5…55 °C 13. net weight : 1 kg 14. inductance of closed circuit : 5.1 H


    Main (see above)
    range
    TeSys
    product or component type
    Contactor coil
    device short name
    LX1FJ
    range compatibility
    TeSys F LC1F contactor
    product compatibility
    LC1F400
    control circuit type
    AC at 40...400 Hz
    [Uc] control circuit voltage
    220...230 V AC 40...400 Hz
    average resistance
    37 Ohm inrush at 20 °C
    1030 Ohm holding at 20 °C
    inductance of closed circuit
    5.1 H
    operating time
    100...170 ms opening
    40...75 ms closing
    mechanical durability
    10 Mcycles
    maximum operating rate
    2400 cyc/h 55 °C
    Complementary (see above)
    coil technology
    Without built-in suppressor module
    control circuit voltage limits
    Operational: 0.85...1.1 Uc 40...400 Hz (at 55 °C)
    Drop-out: 0.3...0.5 Uc 40...400 Hz (at 55 °C)
    inrush power in VA
    1075 VA 40...400 Hz cos phi 0.9 (at 20 °C)
    hold-in power consumption in VA
    15 VA 40...400 Hz cos phi 0.3 (at 20 °C)
    heat dissipation
    14 W at 40...400 Hz
    Environment (see above)
    ambient air temperature for operation
    -5…55 °C
    net weight
    1 kg
    Packing Units (see above)
    Package 1 Weight
    1.154 kg
    Package 1 Height
    0.950 dm
    Package 1 width
    1.000 dm
    Package 1 Length
    1.900 dm
    Offer Sustainability (see above)
    Sustainable offer status
    Green Premium product
    REACh Regulation
    REACh free of SVHC
    Yes
    EU RoHS Directive
    Pro-active compliance (Product out of EU RoHS legal scope)
    EU RoHS Declaration
    Toxic heavy metal free
    Yes
    Mercury free
    Yes
    RoHS exemption information
    China RoHS Regulation
    Environmental Disclosure
    Circularity Profile
    Contractual warranty (see above)
    Warranty
    12 months
