  2. Contactor
  3. Contactor
  4. Schneider TeSys F - specific contactor coil - 110...115 V AC 40...400 Hz low consumption

Schneider TeSys F - specific contactor coil - 110...115 V AC 40...400 Hz low consumption

Rp 1.862.580,00 Rp 819.535,00 819535 IDR

Rp 1.862.580,00

Option not available

    This combination does not exist.

    Add to Cart

    Schneider TeSys F - specific contactor coil - 110...115 V AC 40...400 Hz low consumption
    Terjual 0
    0 (0 Rating)
    Ulasan (0)

    Rp 819.535,00
    56.00 % Rp 1.862.580,00 819535 IDR

    Rp 1.862.580,00

    Option not available

    Atur Jumlah & Catatan
    Stock Total: 1
    Keranjang Beli Sekarang
    Spesifikasi
    Main (see above)
    range
    TeSys
    product or component type
    Specific contactor coil
    device short name
    LX9FF
    range compatibility
    TeSys F LC1F contactor
    product compatibility
    LC1F115
    LC1F150
    control circuit type
    AC at 40...400 Hz low consumption
    [Uc] control circuit voltage
    110...115 V AC 40...400 Hz
    average resistance
    14.8 Ohm inrush at 20 °C
    579 Ohm holding at 20 °C
    inductance of closed circuit
    2.08 H
    operating time
    130 ms opening
    35 ms closing
    mechanical durability
    10 Mcycles
    maximum operating rate
    2400 cyc/h 55 °C
    Complementary (see above)
    coil technology
    Without built-in suppressor module
    control circuit voltage limits
    Operational: 0.85...1.1 Uc (at 55 °C)
    Drop-out: 0.35...0.55 Uc (at 55 °C)
    inrush power in VA
    690…855 VA 40...400 Hz (at 20 °C)
    hold-in power consumption in VA
    6.6…8.1 VA 40...400 Hz (at 20 °C)
    heat dissipation
    5.9…7.2 W
    Environment (see above)
    ambient air temperature for operation
    -5…55 °C
    net weight
    0.43 kg
    Packing Units (see above)
    Unit Type of Package 1
    PCE
    Number of Units in Package 1
    1
    Package 1 Weight
    524 g
    Package 1 Height
    7.5 cm
    Package 1 width
    10.5 cm
    Package 1 Length
    17.7 cm
    Offer Sustainability (see above)
    Sustainable offer status
    Green Premium product
    REACh Regulation
    REACh free of SVHC
    Yes
    EU RoHS Directive
    Pro-active compliance (Product out of EU RoHS legal scope)
    EU RoHS Declaration
    Mercury free
    Yes
    RoHS exemption information
    China RoHS Regulation
    Environmental Disclosure
    Circularity Profile
    Contractual warranty (see above)
    Warranty
    12 months
