Schneider Analogue I/O extension module - 4 I O - 24 V DC - for Zelio Logic

Rp 3.427.458,00 Rp 1.953.651,00 1953651 IDR

Rp 3.427.458,00

Option not available

    This combination does not exist.

    Add to Cart

    Schneider Analogue I/O extension module - 4 I O - 24 V DC - for Zelio Logic
    Terjual 0
    0 (0 Rating)
    Ulasan (0)

    Rp 1.953.651,00
    43.00 % Rp 3.427.458,00 1953651 IDR

    Rp 3.427.458,00

    Option not available

    Atur Jumlah & Catatan
    Stock Total: 29
    Keranjang Beli Sekarang
    Spesifikasi
    Main (see above)
    range of product
    Zelio Logic
    product or component type
    Analogue I/O extension module
    Complementary (see above)
    analogue input number
    2
    analogue input type
    Common mode
    analogue input range
    0...10 V
    0...20 mA
    -25...125 °C
    temperature probe type
    Pt 100, 3-wire conforming to IEC 751
    maximum permissible voltage
    30 V for analogue input circuit
    [Imp] maximum permanent current
    30 mA for analogue input circuit
    analogue input resolution
    10 bits on the input range
    input impedance
    18 kOhm, input range: 0...10 V for analogue input circuit
    247 Ohm, input range: 0...20 mA for analogue input circuit
    analogue output number
    2
    analogue output range
    0...10 V
    analogue output resolution
    10 bits on the output range
    load type
    Resistive load for analogue output
    maximum load current
    10 mA for analogue output
    short-circuit protection
    With analogue output
    LSB value
    0.15 °C, - 25...125 °C for analogue input circuit
    20 µA, 0...20 mA for analogue input circuit
    9.8 mV, 0...10 V for analogue input circuit
    9.8 mV, 0...10 V for analogue output
    conversion time
    Smart relay cycle time for analogue input circuit
    Smart relay cycle time for analogue output
    conversion error
    +/- 1 % of the full scale value, input range: 0...10 V (25 °C) for analogue output
    +/- 1 % of the full scale value, input range: 0...10 V (55 °C) for analogue output
    +/- 1 %, input range: 0...10 V (25 °C) for analogue input circuit
    +/- 1 %, input range: 0...10 V (55 °C) for analogue input circuit
    +/- 1 %, input range: 0...20 mA (25 °C) for analogue input circuit
    +/- 1 %, input range: 0...20 mA (55 °C) for analogue input circuit
    +/- 1.5 °C, input range: - 25...125 °C (25 °C) for analogue input circuit
    +/- 1.5 °C, input range: - 25...125 °C (55 °C) for analogue input circuit
    repeat accuracy
    < +/- 0.3 °C, input range: - 25...125 °C at 25 °C for analogue input circuit
    <= +/- 1 %, input range: 0...10 V at 25 °C for analogue input circuit
    <= +/- 1 %, input range: 0...10 V at 55 °C for analogue output
    <= +/- 1 %, input range: 0...20 mA at 25 °C for analogue input circuit
    operating distance
    10 m with screened cable for analogue input circuit
    10 m with screened cable for analogue output
    reverse polarity protection
    Analogue input circuit: with
    connections - terminals
    Screw terminals, 1 x 0.25...1 x 2.5 mm² (AWG 24...AWG 14) semi-solid
    Screw terminals, 1 x 0.25...1 x 2.5 mm² (AWG 24...AWG 14) solid
    Screw terminals, 2 x 0.25...2 x 1.5 mm² (AWG 23...AWG 16) solid
    Screw terminals, 1 x 0.25...1 x 2.5 mm² (AWG 24...AWG 14) flexible with cable end
    Screw terminals, 2 x 0.25...2 x 0.75 mm² (AWG 24...AWG 18) flexible with cable end
    tightening torque
    0.5 N.m
    net weight
    0.11 kg
    Environment (see above)
    product certifications
    GOST
    UL
    C-Tick
    CSA
    standards
    EN/IEC 61000-4-12
    EN/IEC 61000-4-5
    EN/IEC 61000-4-3
    EN/IEC 61000-4-4 level 3
    EN/IEC 61000-4-6 level 3
    EN/IEC 61000-4-2 level 3
    EN/IEC 60068-2-6 Fc
    EN/IEC 61000-4-11
    EN/IEC 60068-2-27 Ea
    IP degree of protection
    IP20 (terminal block) conforming to IEC 60529
    IP40 (front panel) conforming to IEC 60529
    environmental characteristic
    EMC directive conforming to EN/IEC 61000-6-2
    EMC directive conforming to EN/IEC 61000-6-3
    EMC directive conforming to EN/IEC 61000-6-4
    EMC directive conforming to EN/IEC 61131-2 zone B
    Low voltage directive conforming to EN/IEC 61131-2
    disturbance radiated/conducted
    Class B conforming to EN 55022-11 group 1
    pollution degree
    2 conforming to EN/IEC 61131-2
    ambient air temperature for operation
    -20…40 °C conforming to IEC 60068-2-1 and IEC 60068-2-2
    -20…55 °C conforming to IEC 60068-2-1 and IEC 60068-2-2
    ambient air temperature for storage
    -40…70 °C
    operating altitude
    2000 m
    maximum altitude transport
    3048 m
    relative humidity
    95 % without condensation or dripping water
    Packing Units (see above)
    Unit Type of Package 1
    PCE
    Number of Units in Package 1
    1
    Package 1 Weight
    107 g
    Package 1 Height
    6.1 cm
    Package 1 width
    6.5 cm
    Package 1 Length
    11 cm
    Unit Type of Package 2
    S03
    Number of Units in Package 2
    48
    Package 2 Weight
    5.585 kg
    Package 2 Height
    30 cm
    Package 2 width
    30 cm
    Package 2 Length
    40 cm
    Offer Sustainability (see above)
    Sustainable offer status
    Green Premium product
    REACh Regulation
    EU RoHS Directive
    Pro-active compliance (Product out of EU RoHS legal scope)
    EU RoHS Declaration
    Mercury free
    Yes
    RoHS exemption information
    China RoHS Regulation
    Environmental Disclosure
    Circularity Profile
    WEEE
    The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins
    PVC free
    Yes
    Contractual warranty (see above)
    Warranty
    12 months
