Spesifikasi
| range | Domae | |
|---|---|---|
| product or component type | Miniature circuit-breaker | |
| device short name | Domae MCB | |
| device application | Protection | |
| poles description | 2P | |
| number of protected poles | 1 | |
| neutral position | Left | |
| [In] rated current | 16 A | |
| network type | AC | |
| trip unit technology | Thermal-magnetic | |
| curve code | C | |
| breaking capacity | Icn 6000 A | |
| quality labels | CE |
| network frequency | 50/60 Hz | |
|---|---|---|
| [Ue] rated operational voltage | 230 V AC 50/60 Hz | |
| magnetic tripping limit | 5...10 x In | |
| control type | Toggle | |
| mounting mode | Clip-on | |
| mounting support | DIN rail | |
| comb busbar and distribution block compatibility | YES | |
| 9 mm pitches | 4 | |
| height | 81 mm | |
| width | 36 mm | |
| depth | 71.5 mm | |
| net weight | 0.190 kg | |
| colour | White | |
| mechanical durability | 20000 cycles | |
| electrical durability | 10000 cycles | |
| connections - terminals | Tunnel type terminals (top or bottom) - 1...25 mm² - rigid Tunnel type terminals (top or bottom) - 1...16 mm² - flexible | |
| wire stripping length | 14 mm for top or bottom connection | |
| tightening torque | 2 N.m top or bottom | |
| earth-leakage protection | Without |
| standards | IEC 60898-1 | |
|---|---|---|
| product certifications | SNI | |
| IP degree of protection | IP20 conforming to IEC 60529 IP40 (modular enclosure) conforming to IEC 60529 | |
| overvoltage category | III | |
| tropicalisation | 2 conforming to IEC 60068-1 | |
| relative humidity | 95 % at 55 °C | |
| ambient air temperature for operation | -5…60 °C | |
| ambient air temperature for storage | -40…85 °C |
| Sustainable offer status | Green Premium product | |
|---|---|---|
| REACh Regulation | ||
| REACh free of SVHC | Yes | |
| EU RoHS Directive | Compliant EU RoHS Declaration | |
| Toxic heavy metal free | Yes | |
| Mercury free | Yes | |
| RoHS exemption information | ||
| China RoHS Regulation | China RoHS declaration Pro-active China RoHS declaration (out of China RoHS legal scope) | |
| Environmental Disclosure | ||
| WEEE | The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins |
Specifications for Schneider MCB DOMAE 2P 16A 6KA
| # of Pole | 2 |
| Arus Nominal (In) | 16A |
