  4. Schneider Easypact EZC EZC100B 3P 15A 7,5KA

Schneider Easypact EZC EZC100B 3P 15A 7,5KA

# of Pole : 3

Arus Nominal (In) : 15A

Trip Unit Rating : 15 A at 50 °C

Rp 1.007.880,00 Rp 514.018,00 514018 IDR

Rp 1.007.880,00

Option not available

  • # of Pole
  • Arus Nominal (In)
  • Trip Unit Rating

This combination does not exist.

Add to Cart

Schneider Easypact EZC EZC100B 3P 15A 7,5KA
Terjual 0
0 (0 Rating)
Ulasan (0)

Rp 514.018,00
49.00 % Rp 1.007.880,00 514018 IDR

Rp 1.007.880,00

Option not available

Atur Jumlah & Catatan
Stock Total: 37

# of Pole : 3

Arus Nominal (In) : 15A

Trip Unit Rating : 15 A at 50 °C

Keranjang Beli Sekarang
Spesifikasi

Schneider Electric MCCB EasyPact EZC - 15 A - 3P/3d - EZC100B3015 [Deskripsi] -Aplikasi untuk instalasi listrik dengan kapasitas pemutusan rendah. -Kapasitas Pemutusan : 7.5 kA s/d 30 kA pada 380/415 VAC. -Thermal magnetic trip unit, tidak dapat disetel (non adjustable). -Fixed type, front connection. -Satu ukuran (frame size) untuk semua rating. -Memenuhi standar IEC 60947-2. -Rated @ 125V DC (1P) dan @ 250V DC (2P in series) [Spesifikasi] 1. control type : Toggle 2. mounting mode : Fixed 3. mounting support : Backplate 4. upside connection : Front 5. downside connection : Front 6. mechanical durability : 8500 cycles 7. electrical durability : Category A : 1500 cycles 415 V AC 50/60 Hz conforming to IEC 60947-2 8. connection pitch : 25 mm 9. local signalling : Positive contact indication 10. neutral protection setting : Without protection 11. earth-leakage protection : Without 12. height : 130 mm 13. width : 75 mm 14. depth : 60 mm 15. weight: 0.78kg


Main (see above)
range of product
EasyPact
product or component type
Circuit breaker
device short name
Easypact EZC100B
circuit breaker name
Easypact EZC100B
device application
Distribution
poles description
3P
protected poles description
3t
network type
DC
AC
network frequency
50/60 Hz
[In] rated current
100 A at 40 °C
[Ui] rated insulation voltage
690 V AC 50/60 Hz conforming to IEC 60947-2
[Uimp] rated impulse withstand voltage
6 kV conforming to IEC 60947-2
[Ue] rated operational voltage
550 V AC 50/60 Hz conforming to IEC 60947-2
breaking capacity code
B
breaking capacity
10 kA Icu at 110...130 V AC 50/60 Hz conforming to IEC 60947-2
10 kA Icu at 220...240 V AC 50/60 Hz conforming to IEC 60947-2
5 kA Icu at 440 V AC 50/60 Hz conforming to IEC 60947-2
2.5 kA Icu at 550 V AC 50/60 Hz conforming to IEC 60947-2
7.5 kA Icu at 380 V AC 50/60 Hz conforming to IEC 60947-2
7.5 kA Icu at 400...415 V AC 50/60 Hz conforming to IEC 60947-2
[Ics] rated service breaking capacity
0.625 kA at 550 V AC 50/60 Hz conforming to IEC 60947-2
1.25 kA at 440 V AC 50/60 Hz conforming to IEC 60947-2
1.875 kA at 380 V AC 50/60 Hz conforming to IEC 60947-2
1.875 kA at 400/415 V AC 50/60 Hz conforming to IEC 60947-2
2.5 kA at 110/130 V AC 50/60 Hz conforming to IEC 60947-2
2.5 kA at 220/230/240 V AC 50/60 Hz conforming to IEC 60947-2
suitability for isolation
Yes conforming to IEC 60947-2
utilisation category
Category A
trip unit name
TM-D
trip unit technology
Thermal-magnetic
trip unit rating
15 A at 50 °C
protection type
Overload protection
Short-circuit protection
pollution degree
3 conforming to IEC 60664-1
3 conforming to IEC 947-1
Complementary (see above)
control type
Toggle
mounting mode
Fixed
mounting support
Backplate
upside connection
Front
downside connection
Front
mechanical durability
8500 cycles
electrical durability
Category A: 1500 cycles 415 V AC 50/60 Hz conforming to IEC 60947-2
connection pitch
25 mm
local signalling
Positive contact indication
neutral protection setting
Without protection
earth-leakage protection
Without
height
130 mm
width
75 mm
depth
60 mm
Environment (see above)
standards
EN/IEC 60947-2
JIS C8201-2-2
EN/IEC 60947-1
GB/T 14048.2
IP degree of protection
IP20 conforming to IEC 60529
IK degree of protection
IK07 conforming to IEC 62262
ambient air temperature for operation
-25…70 °C
ambient air temperature for storage
-35…85 °C
Packing Units (see above)
Unit Type of Package 1
PCE
Number of Units in Package 1
1
Package 1 Weight
826 g
Package 1 Height
8 cm
Package 1 width
14 cm
Package 1 Length
8.5 cm
Offer Sustainability (see above)
Sustainable offer status
Green Premium product
REACh Regulation
REACh free of SVHC
Yes
EU RoHS Directive
Toxic heavy metal free
Yes
Mercury free
Yes
RoHS exemption information
China RoHS Regulation
Environmental Disclosure
WEEE
The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins
Contractual warranty (see above)
Warranty
12 months
