Schneider Schneider Electric Easypact EZC MCCB EZC100N 1P 15A 1P/1d - EZC100N1015

# of Pole : 1

Arus Nominal (In) : 15A

Rp 627,671.00 Rp 326,388.00 326388 IDR

Rp 627,671.00

Option not available

  • # of Pole
  • Arus Nominal (In)

This combination does not exist.

Add to Cart

Schneider Schneider Electric Easypact EZC MCCB EZC100N 1P 15A 1P/1d - EZC100N1015
Terjual 0
0 (0 Rating)
Ulasan (0)

Rp 326,388.00
48.00 % Rp 627,671.00 326388 IDR

Rp 627,671.00

Option not available

Atur Jumlah & Catatan
Stock Total: Out of Stock

# of Pole : 1

Arus Nominal (In) : 15A

Spesifikasi
Main (see above)
range of product
EasyPact

product or component type
Circuit breaker

device short name
Easypact EZC100N

circuit breaker name
Easypact EZC100N

device application
Distribution

poles description
1P

protected poles description
1t

network type
DC
AC

network frequency
50/60 Hz

[In] rated current
100 A at 40 °C

[Ui] rated insulation voltage
690 V AC 50/60 Hz conforming to IEC 60947-2

[Uimp] rated impulse withstand voltage
6 kV conforming to IEC 60947-2

[Ue] rated operational voltage
125 V DC conforming to IEC 60947-2
415 V AC 50/60 Hz conforming to IEC 60947-2

breaking capacity code
N

breaking capacity
25 kA Icu at 110...130 V AC 50/60 Hz conforming to IEC 60947-2
5 kA Icu at 125 V DC 1P conforming to IEC 60947-2
18 kA Icu at 220...240 V AC 50/60 Hz conforming to IEC 60947-2
2.5 kA Icu at 380 V AC 50/60 Hz conforming to IEC 60947-2
2.5 kA Icu at 400...415 V AC 50/60 Hz conforming to IEC 60947-2

[Ics] rated service breaking capacity
12.5 kA at 110/130 V AC 50/60 Hz conforming to IEC 60947-2
2.5 kA at 125 V DC conforming to IEC 60947-2
9 kA at 220/230/240 V AC 50/60 Hz conforming to IEC 60947-2
1.25 kA at 380 V AC 50/60 Hz conforming to IEC 60947-2
1.25 kA at 400/415 V AC 50/60 Hz conforming to IEC 60947-2

suitability for isolation
Yes conforming to IEC 60947-2

utilisation category
Category A

trip unit name
TM-D

trip unit technology
Thermal-magnetic

trip unit rating
15 A at 50 °C

protection type
Short-circuit protection
Overload protection

pollution degree
3 conforming to IEC 60664-1
3 conforming to IEC 947-1

Complementary (see above)
control type
Toggle

mounting mode
Fixed

mounting support
Backplate

upside connection
Front

downside connection
Front

mechanical durability
8500 cycles

electrical durability
Category A: 1500 cycles 415 V AC 50/60 Hz conforming to IEC 60947-2

connection pitch
25 mm

local signalling
Positive contact indication

neutral protection setting
Without protection

earth-leakage protection
Without

height
130 mm

width
25 mm

depth
60 mm

Environment (see above)
standards
EN/IEC 60947-2
JIS C8201-2-2
GB/T 14048.2
EN/IEC 60947-1

IP degree of protection
IP20 conforming to IEC 60529

IK degree of protection
IK07 conforming to IEC 62262

ambient air temperature for operation
-25…70 °C

ambient air temperature for storage
-35…85 °C

Packing Units (see above)
Unit Type of Package 1
PCE

Number of Units in Package 1
1

Package 1 Weight
348 g

Package 1 Height
14 cm

Package 1 width
4 cm

Package 1 Length
10 cm

Offer Sustainability (see above)
Sustainable offer status
Green Premium product

REACh Regulation
REACh free of SVHC
Yes

EU RoHS Directive
Toxic heavy metal free
Yes

Mercury free
Yes

RoHS exemption information
China RoHS Regulation
Environmental Disclosure
WEEE
The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins

Contractual warranty (see above)
Warranty
12 months

Specifications for Schneider Schneider Electric Easypact EZC MCCB EZC100N 1P 15A 1P/1d - EZC100N1015

# of Pole 1
Arus Nominal (In) 15A
