  4. Schneider Motor circuit breaker, TeSys GV3, 3P, 40 A, magnetic, rotary handle, EverLink terminals

Schneider Motor circuit breaker, TeSys GV3, 3P, 40 A, magnetic, rotary handle, EverLink terminals

# of Pole : 3

Arus Pengenal (A) : 40A

Rp 3,093,769.00 Rp 1,732,510.00 1732510 IDR

Rp 3,093,769.00

Option not available

  • # of Pole
  • Arus Pengenal (A)

This combination does not exist.

Add to Cart

Schneider Motor circuit breaker, TeSys GV3, 3P, 40 A, magnetic, rotary handle, EverLink terminals
Terjual 0
0 (0 Rating)
Ulasan (0)

Rp 1,732,510.00
44.00 % Rp 3,093,769.00 1732510 IDR

Rp 3,093,769.00

Option not available

Atur Jumlah & Catatan
Stock Total: 12

# of Pole : 3

Arus Pengenal (A) : 40A

Keranjang Beli Sekarang
Spesifikasi

[Deskripsi] Pemutus sirkuit motor termal-magnetik dan magnetik hingga 80 A dan 45 kW. Pemutus sirkuit motor TeSys GV3 menyediakan isolasi, kontrol motor dan perlindungan arus berlebih termal dalam satuan lebar standar 55 mm. [Spesifikasi] 1. product name : TeSys GV2 2. device short name : GV2L 3. device application : Motor 4. poles description : 3P 5. network type : AC 6. utilisation category : -Category A conforming to IEC 60947-2 -AC-3 conforming to IEC 60947-4-1 7. network frequency : 50/60 8. breaking capacity : -100 kA Icu at 230/240 V AC 50/60 Hz -100 kA Icu at 400/415 V AC 50/60 Hz -50 kA Icu at 440 V AC 50/60 Hz -12 kA Icu at 500 V AC 50/60 Hz -6 kA Icu at 690 V AC 50/60 Hz -50 kA Icu at 400/415 V AC 50/60 Hz 9. [Ics] rated service short-circuit breaking capacity -100 % at 230/240 V AC 50/60 Hz -100 % at 400/415 V AC 50/60 Hz -100 % at 440 V AC 50/60 Hz -50 % at 500 V AC 50/60 Hz -50 % at 690 V AC 50/60 Hz 10. trip unit technology : Magnetic 11. magnetic tripping current : 560 A 12. fixing mode : -35 mm symmetrical DIN rail: clipped -Panel: screwed (with 3 x M4 screws) 13. operating position : Any position 14. motor power kW : -18.5 kW at 400/415 V AC 50/60 Hz -22 kW at 500 V AC 50/60 Hz -37 kW at 690 V AC 50/60 Hz 15. control type : Rotary knob 16. [Ue] rated operational voltage : 690 V AC 50/60 Hz conforming to IEC 60947-2 17. [Ui] rated insulation voltage : 690 V AC 50/60 Hz conforming to IEC 60947-2 18. [Uimp] rated impulse withstand voltage : 6 kV conforming to IEC 60947-2 19. mechanical durability : 50000 cycles 20. electrical durability : 50000 cycles for AC-3 at 415 V 21. maximum operating rate : 25 cyc/h 22. rated duty : Continuous conforming to IEC 60947-4-1 23. height : 132 mm 24. width : 55 mm 25. depth : 136 mm 26. net weight : 0.96 kg


Main (see above)
range
TeSys
product name
TeSys GV3
product or component type
Circuit breaker
device short name
GV3L
device application
Motor
poles description
3P
network type
AC
utilisation category
Category A conforming to IEC 60947-2
AC-3 conforming to IEC 60947-4-1
network frequency
50/60 Hz
breaking capacity
100 kA Icu at 230/240 V AC 50/60 Hz
50 kA Icu at 440 V AC 50/60 Hz
12 kA Icu at 500 V AC 50/60 Hz
6 kA Icu at 690 V AC 50/60 Hz
50 kA Icu at 400/415 V AC 50/60 Hz
[Ics] rated service short-circuit breaking capacity
100 % at 230/240 V AC 50/60 Hz
100 % at 400/415 V AC 50/60 Hz
100 % at 440 V AC 50/60 Hz
50 % at 500 V AC 50/60 Hz
50 % at 690 V AC 50/60 Hz
trip unit technology
Magnetic
magnetic tripping current
560 A
Complementary (see above)
fixing mode
35 mm symmetrical DIN rail: clipped
Panel: screwed (with 3 x M4 screws)
operating position
Any position
motor power kW
18.5 kW at 400/415 V AC 50/60 Hz
22 kW at 500 V AC 50/60 Hz
37 kW at 690 V AC 50/60 Hz
control type
Rotary knob
[Ue] rated operational voltage
690 V AC 50/60 Hz conforming to IEC 60947-2
[Ui] rated insulation voltage
690 V AC 50/60 Hz conforming to IEC 60947-2
[Uimp] rated impulse withstand voltage
IEC 60947-2 6 kV
mechanical durability
50000 cycles
electrical durability
50000 cycles for AC-3 at 415 V
maximum operating rate
25 cyc/h
connections - terminals
EverLink BTR screw connectors 1 cable(s) 1…35 mm² solid
EverLink BTR screw connectors 2 cable(s) 1…25 mm² solid
EverLink BTR screw connectors 1 cable(s) 1…35 mm² flexible without cable end
EverLink BTR screw connectors 2 cable(s) 1…25 mm² flexible without cable end
EverLink BTR screw connectors 1 cable(s) 1…35 mm² flexible with cable end
EverLink BTR screw connectors 2 cable(s) 1…25 mm² flexible with cable end
tightening torque
5 N.m on EverLink BTR screw connectors for cable 25 mm²
8 N.m on EverLink BTR screw connectors for cable 35 mm²
mechanical robustness
Shocks: 15 Gn for 11 ms closed conforming to IEC 60068-2-27
Shocks: 30 Gn for 11 ms opened conforming to IEC 60068-2-27
Vibrations: 4 Gn, 5...300 Hz conforming to IEC 60068-2-6
suitability for isolation
Yes conforming to IEC 60947-1
height
132 mm
width
55 mm
depth
136 mm
net weight
0.96 kg
Environment (see above)
standards
EN/IEC 60947-2
EN/IEC 60947-4-1
CSA C22.2 No 60947-4-1
UL 60947-4-1
product certifications
IECEE CB Scheme
UL
CSA
CCC
EAC
ABS
LROS (Lloyds register of shipping)
DNV-GL
BV
protective treatment
TH
IP degree of protection
IP20 conforming to IEC 60529
IK degree of protection
IK09
ambient air temperature for operation
-20…60 °C
ambient air temperature for storage
-40…80 °C
fire resistance
960 °C conforming to IEC 60695-2-1
operating altitude
0...3000 m
Packing Units (see above)
Unit Type of Package 1
PCE
Number of Units in Package 1
1
Package 1 Weight
975 g
Package 1 Height
6.5 cm
Package 1 width
14.5 cm
Package 1 Length
16 cm
Unit Type of Package 2
CAR
Number of Units in Package 2
1
Package 2 Weight
978 g
Package 2 Height
16 cm
Package 2 width
6.5 cm
Package 2 Length
14.5 cm
Unit Type of Package 3
P06
Number of Units in Package 3
120
Package 3 Weight
130 kg
Package 3 Height
80 cm
Package 3 width
80 cm
Package 3 Length
60 cm
Offer Sustainability (see above)
Sustainable offer status
Green Premium product
REACh Regulation
EU RoHS Directive
Mercury free
Yes
RoHS exemption information
China RoHS Regulation
China RoHS declaration
Product out of China RoHS scope. Substance declaration for your information
Environmental Disclosure
WEEE
The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins
California proposition 65
WARNING: This product can expose you to chemicals including: Antimony oxide & Antimony trioxide, which is known to the State of California to cause cancer. For more information go to www.P65Warnings.ca.gov
Contractual warranty (see above)
Warranty
12 months

Specifications for Schneider Motor circuit breaker, TeSys GV3, 3P, 40 A, magnetic, rotary handle, EverLink terminals
